Запчасти Komatsu PC14R-2 ГОЛОВКА ЦИЛИНДРОВ И КОЛЛЕКТОР ДВИГАТЕЛЬ

\0

22J-01-R5101

ENGINE, ASSY.

1

KT1G386-0174-0

HOOK

2

KT01123-60816

BOLT

3

KT16667-5769-2

RETAINER

4

KT1G969-0304-0

HEAD ASSY, CYLINDER

5

KT15321-9626-0

PLUG

6

KT15261-0337-0

PLUG

7

KT15841-1354-0

GUIDE, INTAKE VALVE

8

KT15841-1356-0

GUIDE, EXHAUST VALVE

9

KT15261-9601-0

PLUG

10

KT19837-5792-0

SPRING

11

KT14601-0345-0

BOLT

12

KT16871-0331-0

GASKET

13

KT1G958-1450-2

BONNET ASSY., HEAD

14

KT1G958-1452-0

GASKET

15

KT1G985-0537-0

PLATE

16

KT1G911-0520-2

VALVE, ASSY.

17

KT1G911-0512-0

COVER, DIAPHRAGM

18

KT03024-50510

SCREW

19

KT16241-7337-0

PIPE

20

KT1G911-9102-2

BOLT

21

KTE9151-3314-0

PLUG

22

KT04814-50300

O-RING

23

KT1G958-0551-0

PIPE

24

KT09318-88125

CLAMP

25

KT15841-9602-0

PLUG

26

KT14601-1311-0

VALVE, INTAKE

27

KT14601-1312-0

VALVE, EXHAUST

28

KT14601-1324-0

SPRING, VALVE

29

KT14601-1333-0

RETAINER

30

KT14601-1336-0

COTTER

31

KT16851-1328-0

CAP

32

KT11420-1315-0

SEAL

33

KT15861-1426-3

SHAFT

34

KT16871-1443-0

WASHER

35

KT15841-9402-2

WASHER

36

KT01023-50610

BOLT

37

KT1G958-1435-0

BRACKET

38

KT01754-50640

BOLT

39

KT05411-00420

SPRING PIN

40

KT14601-1431-0

SPRING

41

KT15841-1403-0

ARM ASSY, ROCKER

42

KT15841-1423-0

SCREW, ADJUSTING

43

KT14601-1424-0

NUT

44

KT1G958-1177-0

MANIFOLD ASSY, AIR INTAKE

45

KT1G960-0555-0

PIPE, BREATHER

46

KT15861-1182-0

GASKET

47

KT01023-50618

BOLT

48

KT01023-50645

BOLT

49

KT15862-1231-4

MANIFOLD, EXHAUST

50

KT15862-1235-0

GASKET

51

KT01759-50616

BOLT

52

KT01513-50618

PIN

53

KT02756-50060

NUT

54

KT1G386-1211-0

MUFFLER

55

KT15862-1223-0

GASKET

56

KT01759-50825

BOLT
