Запчасти Komatsu PC14R-2 СТРЕЛА (ДЛЯ ОБОРУД-Е) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

20M-70-R1111

BOOM

2

22J-70-25142

SLEEVE

3

07145-00035

SEAL, DUST

4

22L-46-12150

PLUG

5

22M-06-R1710

WORK LAMP, ASSY

\5

104-06-41410

BULB

6

20P-06-R1310

BRACKET

7

22L-09-R4760

SUPPORT

8

01010-81245

BOLT

9

01643-11232

WASHER

10

22J-06-25222

WIRING HARNESS

11

22J-70-R5150

PIN

12

07020-00000

FITTING, GREASE

13

20N-70-R1280

SPACER, 1.0 mm

14

20M-70-61120

PLATE

15

01010-81020

BOLT

16

01643-11032

WASHER

\16

22J-70-25160

PIN, ASSY.

17

22J-70-25170

PIN

18

07020-00000

FITTING, GREASE

19

04082-00212

LOCK

20

01010-81225

BOLT

21

01643-11232

WASHER

\21

22J-70-25181

PIN, ASSY.

22

22J-70-25191

PIN

23

07020-00000

FITTING, GREASE

24

22L-09-R2460

PLATE

25

20N-70-R1280

SPACER, 1.0 mm

26

01010-81020

BOLT

27

01643-11032

WASHER

28

20N-70-41270

SPACER, 1.0 mm

29

22J-973-R541

PIPE

30

02896-11012

O-RING

31

22J-973-2590

CLAMP

32

01010-81050

BOLT

33

01643-11032

WASHER

34

22J-70-16490

SPACER

35

22J-973-R531

PIPE

36

02896-11012

O-RING

37

37A-09-11002

BOLT
