Запчасти Komatsu PC14R-2 МОТОР ХОДА (/) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

\0

20M-60-91302

TRAVEL MOTOR

\0

FUMHB28613

HUB, ASSY.

1

HUB

2

SEAL

\2

FUMHSH12098

SHAFT, ASSY.

3

SHAFT

4

FU6004

BEARING

\4

FUMHCB14736

CYLINDER, ASSY

5

CYLINDER BLOCK

6

PLATE VALVE

7

PISTON

8

SLIDE

9

DISK

10

THRUST BALL

11

PIN

12

SPRING

13

SPACER

14

840141019

RING, SNAP

\14

FUMHSW2098135

PLATE, ASSY.

15

SWASH PLATE

16

PIN

\16

FUMHBO7BB4616

KIT, BASE PLATE, ASSY.

17

FU6201

BEARING

18

840141038

PIN

19

BASE PLATE

20

SPOOL

21

VALVE

22

REGISTER VALVE

23

SPRING

24

SPRING

25

PLUG

26

PLUG

27

O-RING

28

O-RING

29

FUROP1890

O-RING

30

PLUG

31

PLUG

32

FUROP1090

O-RING

\32

FUMHS007B18613

KIT, GASKET

33

FUROG10090

O-RING

34

SEAL

35

FUROP1890

O-RING

36

FUROP1090

O-RING

37

FU6004

BEARING

38

FU6201

BEARING

39

FUROG10090

O-RING

40

840141019

RING, SNAP

41

840141048

SCREW

42

840141038

PIN

43

FUROP1890

O-RING

44

FUROP1090

O-RING

45

FUPPH76X14

PIN
