Запчасти Komatsu PC138USLC-8 ЦИЛИНДР РУКОЯТИ(№-) ЦИЛИНДР РУКОЯТИ

|$0

707-01-0L681

Cylinder Assembly

|$1

707-01-0L680

Cylinder Assembly

1

707-13-11210

Cylinder

2

707-58-75840

Rod, Piston

3

22B-70-23620

Bushing

4

07145-00070

Seal, Dust, (Kit : K06, K07)

5

22B-70-23620

Bushing

6

07145-00070

Seal, Dust, (Kit : K06, K07)

7

707-71-32460

Collar

8

07000-15100

O-ring, (Kit : K06, K07)

9

707-71-70810

Plunger

10

707-35-31010

Ring, Back-up, (Kit : K07)

10

707-35-91130

Ring, Back-up, (Kit : K06)

11

707-71-80290

Plunger

12

04260-00635

Ball, Steel

13

707-71-91270

Cap

14

707-27-11650

Head, Cylinder

15

707-56-75740

Seal, Dust, (Kit : K06, K07)

16

07179-13089

Ring, Snap

17

707-51-75030

Packing, Rod, (Kit : K06, K07)

18

707-51-75650

Ring, Buffer, (Kit : K06, K07)

19

07000-15100

O-ring, (Kit : K06, K07)

20

707-52-90501

Bushing

21

707-75-75110

Ring, Snap

22

01010-81670

Bolt

23

01643-51645

Washer

24

707-35-31010

Ring, Back-up, (Kit : K07)

24

707-35-91130

Ring, Back-up, (Kit : K06)

25

721-36-11020

Piston

26

707-44-11150

Ring, Piston, (Kit : K06, K07)

27

707-39-11150

Ring, Wear, (Kit : K06, K07)

28

707-44-11911

Ring

29

01310-01216

Screw

30

07000-15070

O-ring, (Kit : K06, K07)

31

707-35-30700

Ring, Back-up, (Kit : K07)

31

707-35-90360

Ring, Back-up, (Kit : K06)

32

707-83-13010

Valve

33

07750-01628

Spring

34

07002-12034

O-ring, (Kit : K06, K07)

35

707-87-14070

Plug

36

707-86-55540

Tube

37

02896-11015

O-ring, (Kit : K06, K07)

38

707-88-50110

Bracket

39

707-88-26250

Band

40

07372-21035

Bolt

41

01643-51032

Washer

42

07283-32236

Clip, Pipe

43

01597-01009

Nut

44

01643-31032

Washer

45

01010-80850

Bolt

46

01643-30823

Washer

47

07000-13025

O-ring, (Kit : K06, K07)
