Запчасти Komatsu PC138USLC-8 КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) (№-) КОНЕЧНАЯ ПЕРЕДАЧА

|$0

22B-60-22112

Motor Assembly

|$1

22B-60-22111

Motor Assembly

|$2

22B-60-22110

Motor Assembly

|$3

TZ600D200002-B

Motor

|$4

TZ600D2205-01

Cylinder and Piston Kit

|$5

Piston Kit

|$6

Piston Assembly

1

Piston

2

Shoe

3

Cylinder Block

3

TZ600D2070-01

Piston Assembly

4

Piston

5

Shoe

6

TZ600D2002-01

Shaft

7

TZ600D200300-B

Swash Plate Assembly

8

TZ600D2007-01

Retainer Assembly

9

TZ600D2008-00

Ball

10

TZ600D2009-01

Timing Plate

11

TZ880A2010-00

Washer

12

TZ600D2012-00

Piston

13

TZ500D2013-00

Spring

14

TZ600D2014-00

Spring

15

TZ600D2015-00

Plate

16

TZ600D2016-00

Plate

17

TZTCZ284810113

Seal, Oil, (Kit : K01)

18

TZ500D2039-00

O-ring, (Kit : K01)

19

TZ600D2039-00

O-ring, (Kit : K01)

20

TZTH-R-42

Ring, Snap

21

TZ600D2048-00

Bearing

22

06000-06304

Bearing

23

TZJB15063-258F

Roller

24

TZ600D2076-01

Pivot

25

TZ263B2077-01

Pin

26

TZ600D2090-00

Spring
