Запчасти Komatsu PC138USLC-8 МЕХАНИЗМ ПОВОРОТА И МОТОР, ВНУТР. ЧАСТИ (/) (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР

|$0

21Y-26-31101

Swing Machinery Assembly

|$1

706-7C-01032

Motor Assembly

|$2

706-7C-03031

Motor Subassembly

1

706-7C-71130

Case, Motor

2

706-7C-71210

Housing

3

706-73-40010

Bearing

4

706-73-42820

Pin

5

706-7C-51110

Valve

6

706-7C-51120

Spring

7

706-7C-51130

Plug

8

07000-B3024

O-ring

9

708-7R-11220

Plug

10

07002-61223

O-ring

11

702-21-55620

Plug

12

07002-61423

O-ring

13

706-7C-51210

Valve Subassembly

14

722-10-91130

Spring

15

706-7C-51230

Plug

16

07002-61823

O-ring

17

07000-B2145

O-ring

18

01252-61245

Bolt, Hexagon Socket Head

19

706-7C-41510

Shaft, Drive

20

706-73-43880

Bearing

21

706-7C-41610

Plate

22

706-73-43890

Bearing

23

706-7C-05110

Spacer Kit

23

Spacer, T=1.5mm

23

Spacer, T=1.7mm

23

Spacer, T=1.9mm

23

Spacer, T=2.1mm

23

Spacer, T=2.3mm

24

04064-03515

Ring, Snap

25

708-7T-12330

Seal, Oil

26

04065-04518

Ring, Snap

27

706-7C-41110

Cylinder Block

28

706-7C-41310

Plate, Valve

29

720-68-19610

Pin

30

706-7C-41210

Shaft,Center

31

706-7C-41410

Ring,Center

32

706-7C-41420

Spring

33

706-7C-41910

Retainer, Shoe

34

706-73-42270

Screw

35

706-7C-41740

Piston Subassembly

36

706-7C-91210

Plate

37

706-7C-91220

Disc

38

706-7C-91110

Piston, Brake

39

706-7C-91120

Ring, Brake

40

07000-B2110

O-ring

41

07000-B2130

O-ring

42

706-7C-91310

Spring
