Запчасти Komatsu PC138USLC-8 РУКОЯТЬ И КОВШ ТРУБЫ, ТРУБЫ (№-) РУКОЯТЬ И КОВШ ТРУБЫ, С -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР

1

22B-62-23492

Hose

1

21U-62-34740

Band, Orange

2

22B-62-23512

Hose

2

21U-62-34730

Band, Green

3

22B-62-23522

Hose

3

21U-62-34760

Band, Red

4

22B-62-23532

Hose

4

21U-62-34750

Band, Blue

5

22B-54-22411

Bracket

6

01010-81655

Bolt

7

01643-31645

Washer

8

08034-20834

Band

9

22B-62-21281

Cushion

10

22B-62-22280

Cushion

11

22B-62-22320

Cushion

12

22B-62-22290

Cushion

13

01010-81235

Bolt

14

01643-31232

Washer

15

22B-62-21321

Plate

16

22B-62-23971

Hose

16

21U-62-34720

Band, Black

17

22B-62-23321

Hose

17

21U-62-34720

Band, Black

17

21U-62-34710

Band, Yellow

18

22B-62-23291

Hose

18

21U-62-34730

Band, Green

18

21U-62-34710

Band, Yellow

19

22B-62-23331

Hose

19

21U-62-34780

Band, Brown

19

21U-62-34710

Band, Yellow

20

22B-62-23331

Hose

20

21U-62-34740

Band, Orange

20

21U-62-34710

Band, Yellow

21

22B-62-23351

Hose

21

21U-62-34770

Band, White

22

22B-62-23361

Hose

22

21U-62-34780

Band, Brown

23

22B-06-21540

Wiring Harness

24

7861-93-1840

Sensor,Travel

24

07000-12011

O-ring

25

08211-00720

Clip
