Запчасти Komatsu PC138USLC-8 МОТОР ХОДА (GMVA ТИП) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC138USLC-8 - МОТОР ХОДА (GMVA ТИП) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
8
9
10
10
11
12
13
14
15
15
16
16
17
17
18
18
19
20
20
21
21
22
22
23
24
24
25
25
26
26
27
28
29
29
30
31
32
33
34
35
36
37
37
38
39
39
40
41
41
42
42
42
43
44
45

Артикул

Название

Примечание

Количество

|$1

22B-60-22110

MOTOR ASS'Y

|$4

TZ600D300000-A

RELEAF VALVE ASS'Y

|$5

TZ600D310000-A

RELEAF ASS'Y

1

VALVE SEAT

2

VALVE

3

SLEEVE

4

COLLER

5

PLUG

6

SPRING

7

TZJB2401-P10A

O-RING (KIT)

8

TZJB2407T2P10A

BACK-UP RING (KIT)

9

07000-12014

O-RING (KIT)

10

TZJB2407T2-P14

RING (KIT)

11

07000-12011

O-RING (KIT)

12

07000-12018

O-RING (KIT)

13

SHIM

|$19

TZ600D400001-B

CONTROL VALVE ASS'Y

|$20

TZ600D410001-B

FLANGE ASS'Y

|$21

TZ600D410101-B

REAR FLANGE KIT

|$22

TZ600D415001-B

SPOOL ASS'Y

14

SPOOL

15

PLUG

16

VALVE

17

SPRING

18

O-RING (KIT)

19

FLANGE

20

PLUG

21

TZ600D4052-01

WASHER

22

TZ100A2055-00

SPRING

23

TZS0506

ORIFICE

24

07000-12032

O-RING (KIT)

25

TZ200C2021-01

PLUG

26

04260-00793

BALL

27

TZGDL1-16-S

PLUG

28

TZ610B2021-00

PLUG

29

07000-11008

O-RING (KIT)

30

07000-12018

O-RING (KIT)

31

TZ600D4069-00

SPOOL

32

TZ420B2089-01

SPRING

33

TZS0505

ORIFICE

34

TZ976B2079-00

FILTER

35

04260-00476

BALL

36

TZ571B2079-00

PLUG

37

TZ720B2021-00

PLUG

38

TZ600D4081-00

PISTON

39

07000-12014

O-RING (KIT)

40

TZS0545

ORIFICE

41

TZGM1-4-G-S

PLUG

42

TZGM1-8-S

PLUG

43

TZ850A0006-00

PLATE, NAME

44

TZJB1354-4-10

PIN

45

01252-31230

BOLT

K

TZ600D9000-00

SERVICE KIT

Выбрано товаров: 53
