Запчасти Komatsu PC138USLC-8 ОСНОВН. КОНСТРУКЦИЯ (ОТВАЛ УПРАВЛ-Е)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

702-16-01600

PILOT VALVE,(SEE FIG. Y1670-31A0)

2

01010-D1025

BOLT

3

01643-71032

WASHER

4

22B-43-23311

BRACKET

5

01010-81040

BOLT

6

01643-31032

WASHER

7

22B-43-23330

LEVER

8

01010-D0825

BOLT

9

01643-70823

WASHER

10

01583-11408

NUT

11

22U-43-21730

SEAT

12

20Y-43-21231

KNOB

13

01023-20416

SCREW

14

21W-62-43990

ELBOW

15

07000-12011

O-RING

16

02896-11008

O-RING

17

21W-62-43980

ELBOW

18

07000-12011

O-RING

19

02896-11008

O-RING

20

11Y-62-12140

NIPPLE

21

07000-12011

O-RING

22

02896-11008

O-RING

|$30

22B-62-25502

HOSE ASS'Y

23

22B-62-25510

HOSE, 1280MM

23

21U-62-34760

BAND, RED

23

21U-62-34730

BAND, GREEN

24

22B-62-25520

HOSE, 1370MM

24

21U-62-34750

BAND, BLUE

24

21U-62-34770

BAND, WHITE

25

22B-62-25531

HOSE, 1880MM

25

21U-62-34760

BAND, RED

25

21U-62-34720

BAND, BLACK

26

22B-62-25541

HOSE, 2040MM

26

21U-62-34710

BAND, YELLOW

26

21U-62-34750

BAND, BLUE

27

22B-43-23580

SHEET

28

22B-54-16461

RIVET
