Запчасти Komatsu PC138USLC-2 ЦИЛИНДР СТРЕЛЫ(ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XZA60

CYLINDER GROUP,L.H. (FINAL COATING)

G1

707-01-XZA70

CYLINDER GROUP,R.H. (FINAL COATING)

G1

707-01-XG120

CYLINDER GROUP,L.H.

G1

707-01-XG130

CYLINDER GROUP,R.H.

|$$5

====================

|$5

707-01-0G120

CYLINDER ASS'Y

1

707-13-10550

CYLINDER

2

21K-70-71320

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-27-10971

HEAD,CYLINDER

6

707-52-90470

BUSHING

7

707-51-70030

PACKING,ROD (KIT)

8

707-51-70640

RING,BUFFER (KIT)

9

707-71-32420

COLLAR

10

07000-15095

O-RING (KIT)

11

707-35-91060

RING,BACK-UP (KIT)

12

144-63-95170

SEAL,DUST (KIT)

13

07179-12084

RING,SNAP

14

01010-81465

BOLT

15

705-17-04980

WASHER

16

721-58-70210

ROD

17

21K-70-71320

BUSHING

18

07145-00070

SEAL,DUST (KIT)

19

707-71-70700

PLUNGER

20

707-36-10760

PISTON

21

707-44-10280

RING,PISTON (KIT)

22

707-39-10550

RING,WEAR (KIT)

23

707-44-10911

RING

24

01310-01216

SCREW

25

707-34-60030

O-RING (KIT)

26

707-35-90730

RING,BACK-UP (KIT)

27

707-86-55160

TUBE,L.H.

27

707-86-55180

TUBE,R.H.

28

707-86-55170

TUBE,L.H.

28

707-86-55190

TUBE,R.H.

29

07000-13025

O-RING (KIT)

30

01010-80850

BOLT

31

01643-50823

WASHER

32

707-88-21720

BAND

33

707-88-25460

BRACKET

34

01010-81035

BOLT

35

01643-51032

WASHER

36

01010-81030

BOLT

37

01643-31032

WASHER

38

02896-11012

O-RING (KIT)

39

02896-11012

O-RING (KIT)

|$$48

====================

|$$49

SERVICE KIT

K

707-99-37340

SERVICE KIT,BOOM CYLINDER
