Запчасти Komatsu PC138USLC-2 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

22B-63-X2430

CYLINDER GROUP,(STRATO BLUE)

G1

22B-63-X2240

CYLINDER GROUP,(NATURAL YELLOW)

|$3

22B-63-02240

CYLINDER ASS'Y,BUCKET

1

22B-63-75540

CYLINDER,BUCKET

2

707-76-65210

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

707-27-10910

HEAD,CYLINDER

6

707-52-90420

BUSHING

7

707-51-65030

PACKING,ROD (KIT)

8

707-51-65630

RING,BUFFER (KIT)

9

07000-15090

O-RING (KIT)

10

707-35-91020

RING,BACK-UP (KIT)

11

144-63-92170

SEAL,DUST (KIT)

12

07179-12079

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

22B-63-75520

ROD,PISTON

16

707-76-65220

BUSHING

17

707-77-65110

SEAL,DUST (KIT)

18

07020-00675

FITTING,GREASE

19

707-36-10720

PISTON

20

707-44-10180

RING,PISTON (KIT)

21

707-39-10110

RING,WEAR (KIT)

22

707-44-10411

RING

23

01310-01016

SCREW

24

707-34-55020

O-RING (KIT)

25

707-35-90610

RING,BACK-UP (KIT)

26

22B-63-75570

TUBE

27

202-63-74580

TUBE

28

07000-13025

O-RING (KIT)

29

01010-80850

BOLT

30

01643-50823

WASHER

31

707-88-95010

CLAMP

32

22B-63-75590

BRACKET

33

01010-81035

BOLT

34

01643-51032

WASHER

35

01010-81025

BOLT

36

01643-31032

WASHER

K

707-99-36300

SERVICE KIT,BUCKET CYLINDER
