Запчасти Komatsu PC138USLC-10 ЦИЛИНДР РУКОЯТИ(№-) ЦИЛИНДР РУКОЯТИ

Схема запчастей Komatsu PC138USLC-10 - ЦИЛИНДР РУКОЯТИ(№-) ЦИЛИНДР РУКОЯТИ
32
33
34
31
30
29
35
31
28
27
26
25
10
6
5
13
12
11
2
24
23
16
15
20
19
6
8
4
28
27
18
17
21
14
8
9
7
4
3
1
42
36
49
47
48
39
38
40
41
43
44
22
37
46
45

Артикул

Название

Примечание

Количество

|$0

707-E1-02090

Cylinder Assembly

1

707-13-11960

Cylinder

2

707-58-75A10

Rod, Piston

3

22B-70-23620

Bushing

4

07145-00070

Seal, Dust, (Kit : K06)

5

22B-70-23620

Bushing

6

07145-00070

Seal, Dust, (Kit : K06)

7

707-71-35250

Collar

8

707-35-31010

Ring, Back-up, (Kit : K06)

9

07000-B5100

O-ring, (Kit : K06)

10

707-71-70810

Plunger

11

707-71-80330

Plunger

12

04260-00635

Ball, Steel

13

707-71-91270

Cap

14

707-27-11650

Head, Cylinder

15

707-56-75740

Seal, Dust, (Kit : K06)

16

07179-13089

Ring, Snap

17

707-51-75860

Packing, Rod, (Kit : K06)

18

707-51-75650

Ring, Buffer, (Kit : K06)

19

07000-B5100

O-ring, (Kit : K06)

20

707-35-31010

Ring, Back-up, (Kit : K06)

21

707-52-90501

Bushing

22

707-75-75110

Ring, Snap

23

01010-81670

Bolt

24

01643-51645

Washer

25

721-36-11020

Piston

26

707-44-11150

Ring, Piston, (Kit : K06)

27

707-39-11150

Ring, Wear, (Kit : K06)

28

707-44-11911

Ring

29

01310-01216

Screw

30

07000-B5070

O-ring, (Kit : K06)

31

707-35-30700

Ring, Back-up, (Kit : K06)

32

707-83-13010

Valve

33

07750-01628

Spring

34

07002-12034

O-ring, (Kit : K06)

35

707-87-14070

Plug

36

707-86-69410

Tube

37

02896-61018

O-ring, (Kit : K06)

38

707-88-51650

Bracket

39

707-88-26250

Band

40

07372-21035

Bolt

41

01643-51032

Washer

42

07283-32738

Clip, Pipe

43

01643-31032

Washer

44

01597-01009

Nut

45

07372-21060

Bolt

46

01643-51032

Washer

47

07372-21045

Bolt

48

01643-51032

Washer

49

07000-13030

O-ring, (Kit : K06)

Выбрано товаров: 50
