Запчасти Komatsu PC138USLC-10 ЦИЛИНДР СТРЕЛЫ, ПРАВ. (№-) ЦИЛИНДР СТРЕЛЫ

|$0

707-E1-02130

Cylinder Assembly

1

707-13-10750

Cylinder

2

707-58-70C00

Rod, Piston

3

07020-00000

Fitting, Grease

4

22B-70-23620

Bushing

5

07145-00070

Seal, Dust, (Kit : K05)

6

22B-70-23620

Bushing

7

07145-00070

Seal, Dust, (Kit : K05)

8

707-71-35260

Collar

9

707-35-30960

Ring, Back-up, (Kit : K05)

10

07000-B5095

O-ring, (Kit : K05)

11

707-71-70780

Plunger

12

707-27-10750

Head, Cylinder

13

707-56-70740

Seal, Dust, (Kit : K05)

14

07179-12084

Ring, Snap

15

707-51-70860

Packing, Rod, (Kit : K05)

16

707-51-70650

Ring, Buffer, (Kit : K05)

17

707-52-90471

Bushing

18

707-75-70110

Ring, Snap

19

07000-B5095

O-ring, (Kit : K05)

20

707-35-30960

Ring, Back-up, (Kit : K05)

21

01010-81465

Bolt

22

705-17-04980

Washer

23

707-36-10760

Piston

24

707-44-10250

Ring, Piston, (Kit : K05)

25

707-39-10550

Ring, Wear, (Kit : K05)

26

707-44-10911

Ring

27

01310-01216

Screw

28

707-34-60070

O-ring, (Kit : K05)

29

707-35-30630

Ring, Back-up, (Kit : K05)

30

707-86-56170

Tube

31

02896-61012

O-ring, (Kit : K05)

32

707-86-55190

Tube

33

02896-61015

O-ring

34

01010-80850

Bolt

35

01643-30823

Washer

36

01010-81030

Bolt

37

01643-31032

Washer

38

07000-13025

O-ring, (Kit : K05)

39

07372-21035

Bolt

40

01643-51032

Washer

41

707-88-21720

Band

42

707-88-25460

Bracket
