Запчасти Komatsu PC138US-8 РУКОЯТЬ И КОВШ ТРУБЫ, ТРУБЫ (№-) РУКОЯТЬ И КОВШ ТРУБЫ, С ОТВАЛ
№
Артикул
Название
Примечание
Количество
1
22B-62-23492
Hose
1
21U-62-34740
Band, Orange
2
22B-62-23512
Hose
2
21U-62-34730
Band, Green
3
22B-62-23522
Hose
3
21U-62-34760
Band, Red
4
22B-62-23532
Hose
4
21U-62-34750
Band, Blue
5
22B-54-22411
Bracket
6
01010-81655
Bolt
7
01643-31645
Washer
8
08034-20834
Band
9
22B-62-22340
Cushion
10
22B-62-22330
Cushion
11
22B-62-22320
Cushion
12
22B-62-22290
Cushion
13
01010-81235
Bolt
14
01643-31232
Washer
15
22B-62-21321
Plate
16
22B-62-23971
Hose
16
21U-62-34720
Band, Black
17
22B-62-23361
Hose
17
21U-62-34780
Band, Brown
18
22B-62-23351
Hose
18
21U-62-34770
Band, White
19
22B-62-23331
Hose
19
21U-62-34740
Band, Orange
19
21U-62-34710
Band, Yellow
20
22B-62-23331
Hose
20
21U-62-34780
Band, Brown
20
21U-62-34710
Band, Yellow
21
22B-62-23411
Hose
21
21U-62-34720
Band, Black
21
21U-62-34750
Band, Blue
22
22B-62-23341
Hose
22
21U-62-34730
Band, Green
22
21U-62-34750
Band, Blue
23
22B-62-22940
Hose
23
21U-62-34750
Band, Blue
23
21U-62-34710
Band, Yellow
24
22B-62-22940
Hose
24
21U-62-34760
Band, Red
24
21U-62-34720
Band, Black
25
22B-06-21490
Wiring Harness
26
22B-06-21560
Wiring Harness
27
7861-93-1840
Sensor,Travel
27
07000-12011
O-ring
28
08211-00720
Clip
29
08057-14012
Clip
30
01010-81025
Bolt
31
01643-31032
Washer
Выбрано товаров: 51
