Запчасти Komatsu PC138US-8 РУКОЯТЬ, РУКОЯТЬ И ЦИЛИНДР КОВША ТРУБЫ (№-) РУКОЯТЬ, MM, С -ДОПОЛН. АКТУАТОР ТРУБЫ, ДЛЯ АВСТРАЛИИ

|$0

22B-943-0061

Arm Assembly

1

Arm

2

202-973-6321

Bracket,Welded

3

22B-943-1220

Bracket,Welded

4

22B-943-1230

Bracket,Welded

5

20T-54-74510

Cap

6

203-70-72210

Bushing

7

203-70-42182

Bushing

8

22B-70-23670

Bushing

9

07020-00900

Fitting, Grease

10

07020-00000

Fitting, Grease

11

22B-70-12230

Seal, Dust

12

21W-70-41440

Seal, Dust

13

203-70-42121

Pin

14

205-70-66580

Plate

15

01010-81230

Bolt

16

01643-31232

Washer

17

21Y-70-14790

Spacer, T=1.0mm

18

21Y-70-14820

Spacer, T=2.0mm

19

07020-00675

Fitting, Grease

20

202-70-52121

Pin

21

21Y-70-14710

Spacer, T=1.0mm

22

205-70-66580

Plate

23

01010-81230

Bolt

24

01643-31232

Washer

25

22B-62-21910

Hose

26

22B-62-21920

Hose

27

07371-30500

Flange, Split

28

01010-80830

Bolt

29

01643-50823

Washer

30

07000-13022

O-ring

31

22B-70-21810

Tube

|$32

22B-70-21810

Tube

|$33

22B-70-21810

Tube

|$34

22B-70-21810

Tube

|$35

22B-70-21810

Tube

|$36

22B-70-21810

Tube
