Запчасти Komatsu PC138US-8 ЦИЛИНДР СТРЕЛЫ, ПРАВ. (№-) ЦИЛИНДР СТРЕЛЫ, M, ДЛЯ MACHINE С СТРЕЛА HOLDING КЛАПАН, С СИГНАЛИЗ. ПЕРЕГРУЗКИ

|$0

707-01-0L660

Cylinder Assembly

1

707-13-10550

Cylinder

2

721-58-70210

Rod, Piston

3

07020-00000

Fitting, Grease

4

22B-70-23620

Bushing

5

07145-00070

Seal, Dust, (Kit : K06)

6

22B-70-23620

Bushing

7

07145-00070

Seal, Dust, (Kit : K06)

8

707-71-32470

Collar

9

07000-15095

O-ring, (Kit : K06)

10

707-71-70780

Plunger

11

707-35-91060

Ring, Back-up, (Kit : K06)

12

707-27-10750

Head, Cylinder

13

707-56-70740

Seal, Dust, (Kit : K06)

14

07179-12084

Ring, Snap

15

707-51-70030

Packing, Rod, (Kit : K06)

16

707-51-70650

Ring, Buffer, (Kit : K06)

17

707-52-90471

Bushing

18

707-75-70110

Ring, Snap, (Kit : K06)

19

07000-15095

O-ring, (Kit : K06)

20

707-35-91060

Ring, Back-up, (Kit : K06)

21

01010-81465

Bolt

22

705-17-04980

Washer

23

707-36-10760

Piston

24

707-44-10250

Ring, Piston, (Kit : K06)

25

707-39-10550

Ring, Wear, (Kit : K06)

26

707-44-10911

Ring

27

01310-01216

Screw

28

707-34-60030

O-ring, (Kit : K06)

29

707-35-90730

Ring, Back-up, (Kit : K06)

30

707-86-55180

Tube

31

02896-11012

O-ring, (Kit : K06)

32

01010-80850

Bolt

33

01643-30823

Washer

34

07000-13025

O-ring, (Kit : K06)

35

707-88-25460

Bracket

36

707-88-21720

Band

37

07372-21035

Bolt

38

01643-51032

Washer

39

01010-81030

Bolt

40

01643-31032

Washer
