Запчасти Komatsu PC138US-8 КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) (№-) КОНЕЧНАЯ ПЕРЕДАЧА, ДЛЯ TRACTION UP КОНЕЧНАЯ ПЕРЕДАЧА 1 SPEED

|$0

22B-Z58-1510

Motor Assembly

|$1

22B-60-11351

Motor Assembly

|$2

TZ476Q1000-00

Final Drive Assembly

|$3

TZ476B1000-00

Final Drive Assembly

1

TZ420A1001-00

Hub

1

TZ476Q1102-00

Spindle Kit

1

TZ467B1102-00

Spindle Kit

1

TZ476Q1132-00

Spindle Assembly

1

TZ467B1132-00

Spindle Assembly

2

Spindle

2

Spindle

3

Flange

3

Flange

4

Bolt

4

TZ481B1019-00

Bolt

5

Pin

6

Washer

6

TZ481B1037-00

Washer

6

TZ481B1104-01

Gear Assembly

6

TZ481B1204-00

Gear Kit

7

Gear

8

Gear

9

Shaft

9

Shaft

10

Spacer

11

Bearing

12

Bearing

13

TZ482B1006-00

Gear

13

TZ482B1107-00

Gear Kit, Spur

14

Gear, Spur

15

TZ481B1008-01

Cover

16

TZ460B1024-01

Coupling

17

TZ481B1017-00

Pin

18

TZ200A1020-00

Ring, Snap

19

TZ481B1021-00

Bearing

20

04064-03818

Ring, Snap, for Shaft Side

21

07000-11007

O-ring, (Kit : K02)

22

TZJW1516-G41-9

O-ring, (Kit : K02)

23

TZARP568-453-7

O-ring, (Kit : K02)

24

TZ300-328-40-B

Floating Seal Assembly

24

TZES100-300-B

Seal, (Kit : K02)

25

TZ610B2021-00

Plug

26

TZJB1176M12-30

Bolt

26

TZJB1176M12-32

Bolt

27

04260-01111

Ball

28

TZJB1354-10-28

Pin

29

07000-12018

O-ring, (Kit : K02)
