Запчасти Komatsu PC138US-8 ЛЕВ. COVER, ОСНОВНАЯ РАМА КРЫШКА(№-) ЛЕВ. COVER

|$0

22B-54-21106

Cover Assembly

|$1

22B-54-21105

Cover Assembly

1

Cover

2

22B-54-11743

Plate

3

22B-54-12660

Shim, T=1.0mm

4

01010-81225

Bolt

5

01643-31232

Washer

6

22B-54-11882

Plate

7

205-54-51971

Dovetail

7

205-54-51970

Dovetail

8

01010-80616

Bolt

9

01643-30623

Washer

10

01010-81225

Bolt

11

01643-31232

Washer

12

22B-54-21481

Bracket

13

01010-81225

Bolt

14

01643-31232

Washer

15

22B-54-21523

Cover

16

203-54-62180

Hinge,Welded

17

20Y-54-71371

Lock,Welded

18

20Y-54-71381

Hook

19

20Y-54-74181

Lock Assembly

20

20Y-54-29232

Bar

21

205-54-53550

Dovetail

22

01010-80616

Bolt

23

01643-30623

Washer

24

01010-81225

Bolt

25

01643-31232

Washer

26

22B-54-24870

Sheet

27

01010-81235

Bolt

28

01643-31232

Washer

29

22B-54-21532

Cover

30

22B-54-21581

Sheet

31

22B-54-22990

Sheet

32

01010-81245

Bolt

33

01643-31232

Washer

34

22B-54-21541

Seal

35

22B-54-22890

Sheet

|$38

22B-54-21871

Cover

36

Cover

37

22B-54-21891

Sheet

38

01010-81220

Bolt

39

01643-31232

Washer

40

22B-54-21430

Cushion
