Запчасти Komatsu PC138US-8 РУКОЯТЬ И КОВШ ТРУБЫ, ТРУБЫ (№-) РУКОЯТЬ И КОВШ ТРУБЫ, С ОТВАЛ, С ДВОЙН. OFFSET СТРЕЛА, СТУПЕНИ, С РУКОЯТЬ HOLDING КЛАПАН, ДЛЯ KUK

1

21Y-62-31411

Hose

1

21U-62-34740

Band, Orange

2

21Y-62-31421

Hose

2

21U-62-34730

Band, Green

3

21Y-62-31431

Hose

3

21U-62-34760

Band, Red

4

21Y-62-31441

Hose

4

21U-62-34750

Band, Blue

5

21Y-62-31451

Hose, Green-Pink

5

21U-62-34730

Band, Green

6

21Y-62-31451

Hose, White-Pink

6

21U-62-34770

Band, White

7

02896-11015

O-ring

8

02896-11012

O-ring

9

21Y-62-31630

Bracket

10

01010-81655

Bolt

11

01643-31645

Washer

12

08034-20834

Band

13

21Y-62-31521

Cushion

14

21Y-62-31531

Cushion

15

21Y-62-31542

Cushion

16

21Y-62-31552

Cushion

17

01010-81235

Bolt

18

01643-31232

Washer

19

22B-62-21321

Plate

20

21Y-62-31641

Guard

21

01010-D1230

Bolt

22

01643-71232

Washer

23

21Y-62-31612

Hose, Blue

24

21Y-62-31622

Hose, Green

24

21U-62-34730

Band, Green

25

21Y-62-31472

Hose, Green-Pink

|$32

21U-62-34730

Band, Green

26

21Y-62-31482

Hose, White-Pink

26

21U-62-34770

Band, White

27

21Y-62-31392

Hose

28

04434-52112

Clip

29

04434-51412

Clip

30

01010-81220

Bolt

31

01643-31232

Washer

32

08034-20834

Band

33

22B-62-23971

Hose

33

21U-62-34720

Band, Black

34

22B-62-23361

Hose

34

21U-62-34780

Band, Brown

35

22B-62-23351

Hose

35

21U-62-34770

Band, White

36

22B-62-23331

Hose

36

21U-62-34740

Band, Orange

36

21U-62-34710

Band, Yellow

37

22B-62-23331

Hose

37

21U-62-34780

Band, Brown

37

21U-62-34710

Band, Yellow

38

22B-62-23411

Hose

38

21U-62-34720

Band, Black

38

21U-62-34750

Band, Blue

39

22B-62-23341

Hose

39

21U-62-34730

Band, Green

39

21U-62-34750

Band, Blue

40

22B-62-22940

Hose

40

21U-62-34750

Band, Blue

40

21U-62-34710

Band, Yellow

41

22B-62-22940

Hose

41

21U-62-34760

Band, Red

41

21U-62-34720

Band, Black

42

22B-06-21490

Wiring Harness

43

22B-06-21560

Wiring Harness

44

7861-93-1840

Sensor,Travel

44

07000-12011

O-ring

45

08211-00720

Clip

46

08057-14012

Clip

47

01010-81025

Bolt

48

01643-31032

Washer

49

21Y-62-31491

Block
