Запчасти Komatsu PC138US-8 РУКОЯТЬ И КОВШ ТРУБЫ, ТРУБЫ (№-) РУКОЯТЬ И КОВШ ТРУБЫ, С -ДОПОЛН. АКТУАТОР ТРУБЫ, С ОТВАЛ

Схема запчастей Komatsu PC138US-8 - РУКОЯТЬ И КОВШ ТРУБЫ, ТРУБЫ (№-) РУКОЯТЬ И КОВШ ТРУБЫ, С -ДОПОЛН. АКТУАТОР ТРУБЫ, С ОТВАЛ
42
42
40
42
43
42
43
41
44
46
45
31
35
38
34
39
39
33
34
32
37
36
32
33
36
35
38
37
31
30
26
28
5
3
4
28
1
2
24
7
6
8
21
22
23
27
25
25
14
27
4
3
5
6
26
9
2
1
24
13
16
15
17
10
11
18
19
20
29
30
12

Артикул

Название

Примечание

Количество

1

21Y-62-31411

Hose

1

21U-62-34740

Band, Orange

2

21Y-62-31411

Hose

2

21U-62-34730

Band, Green

3

21Y-62-31431

Hose

3

21U-62-34760

Band, Red

4

22B-62-29580

Hose, Green-Pink

4

21U-62-34730

Band, Green

5

22B-62-29580

Hose, White-Pink

5

21U-62-34770

Band, White

6

22B-62-29610

Hose

6

21U-62-34750

Band, Blue

7

02896-11015

O-ring

8

02896-11012

O-ring

9

22B-62-29752

Bracket

10

01010-81655

Bolt

11

01643-31645

Washer

12

08034-20834

Band

12

22B-62-29430

Cushion Assembly

13

22B-62-29440

Cushion

14

22B-62-29450

Cushion

15

22B-62-29460

Cushion

16

22B-62-29470

Cushion

17

22B-62-29480

Cushion

18

01010-81235

Bolt

19

01643-31232

Washer

20

22B-946-6470

Bracket

21

22B-62-29761

Bracket

22

01010-81230

Bolt

23

01643-31232

Washer

24

22B-62-29570

Hose

24

21U-62-34730

Band, Green

25

22B-62-29560

Hose

25

21U-62-34750

Band, Blue

26

22B-62-29670

Hose, White-Pink

26

21U-62-34770

Band, White

27

22B-62-29660

Hose, Green-Pink

27

21U-62-34730

Band, Green

28

22B-62-29650

Hose

29

02896-11012

O-ring

30

08034-20834

Band

31

22B-62-23971

Hose

31

21U-62-34720

Band, Black

32

22B-62-23361

Hose

32

21U-62-34780

Band, Brown

33

22B-62-23351

Hose

33

21U-62-34770

Band, White

34

22B-62-23331

Hose

34

21U-62-34740

Band, Orange

34

21U-62-34710

Band, Yellow

35

22B-62-23331

Hose

35

21U-62-34780

Band, Brown

35

21U-62-34710

Band, Yellow

36

22B-62-23411

Hose

36

21U-62-34720

Band, Black

36

21U-62-34750

Band, Blue

37

22B-62-23341

Hose

37

21U-62-34730

Band, Green

37

21U-62-34750

Band, Blue

38

22B-62-22940

Hose

38

21U-62-34750

Band, Blue

38

21U-62-34710

Band, Yellow

39

22B-62-22940

Hose

39

21U-62-34760

Band, Red

39

21U-62-34720

Band, Black

40

22B-06-21490

Wiring Harness

41

22B-06-21560

Wiring Harness

42

7861-93-1840

Sensor,Travel

42

07000-12011

O-ring

43

08211-00720

Clip

44

08057-14012

Clip

45

01010-81025

Bolt

46

01643-31032

Washer

Выбрано товаров: 73
