Запчасти Komatsu PC138US-8 ЦИЛИНДР ОТВАЛА, ЛЕВ. (№-) ЦИЛИНДР ОТВАЛА

|$0

707-01-0L700

Cylinder Assembly

1

707-13-11220

Cylinder

2

707-58-75750

Rod, Piston

3

22B-70-23620

Bushing

4

07145-00070

Seal, Dust, (Kit : K15)

5

07020-00000

Fitting, Grease

6

22B-70-23620

Bushing

7

07145-00070

Seal, Dust, (Kit : K15)

8

07020-00000

Fitting, Grease

9

707-27-11650

Head, Cylinder

10

707-56-75740

Seal, Dust, (Kit : K15)

11

07179-13089

Ring, Snap

12

707-51-75030

Packing, Rod, (Kit : K15)

13

707-51-75650

Ring, Buffer, (Kit : K15)

14

07000-15100

O-ring, (Kit : K15)

15

707-52-90501

Bushing

16

707-75-75110

Ring, Snap

17

01010-81670

Bolt

18

01643-51645

Washer

19

01643-51645

Washer

20

707-35-91130

Ring, Back-up, (Kit : K15)

21

707-88-84990

Bracket

22

01010-81675

Bolt

23

721-36-11020

Piston

24

707-44-11150

Ring, Piston, (Kit : K15)

25

707-39-11150

Ring, Wear, (Kit : K15)

26

707-44-11911

Ring

27

01310-01216

Screw

28

07000-15070

O-ring, (Kit : K15)

29

707-35-90360

Ring, Back-up, (Kit : K15)

30

707-86-55560

Tube

31

02896-11012

O-ring, (Kit : K15)

32

707-86-55240

Tube,L.H.

33

02896-11012

O-ring, (Kit : K15)

34

01010-80850

Bolt

35

01643-30823

Washer

36

707-88-03270

Bracket,L.H.

37

07000-13025

O-ring, (Kit : K15)

38

07283-32236

Clip, Pipe

39

01597-01009

Nut

40

01643-31032

Washer
