Запчасти Komatsu PC138US-8 ЦИЛИНДР КОВША (№-) ЦИЛИНДР КОВША, ДЛЯ KUK

|$0

707-01-0AM90

Cylinder Assembly, Bucket

1

707-13-90260

Cylinder, Bucket

2

202-63-75120

Rod

3

22B-70-23640

Bushing

4

07145-00065

Seal, Dust, (Kit : K13)

5

07020-00900

Fitting, Grease

6

22B-70-23650

Bushing

7

22B-70-12170

Seal, Dust, (Kit : K13)

8

07020-00900

Fitting, Grease

9

707-27-90650

Head, Cylinder

10

707-56-60740

Seal, Dust, (Kit : K13)

11

07179-12074

Ring, Snap

12

707-52-90361

Bushing

13

707-51-60030

Packing, Rod, (Kit : K13)

14

707-51-60650

Ring, Buffer, (Kit : K13)

15

707-35-90980

Ring, Back-up, (Kit : K13)

16

07000-15080

O-ring, (Kit : K13)

17

01010-81465

Bolt

18

705-17-04980

Washer

19

707-75-60110

Ring, Snap

20

707-36-90170

Piston

21

707-44-90150

Ring, Piston, (Kit : K13)

22

707-39-90050

Ring, Wear, (Kit : K13)

23

707-44-90911

Ring

24

07000-15055

O-ring, (Kit : K13)

25

707-35-90920

Ring, Back-up, (Kit : K13)

26

01310-01016

Screw

27

707-86-48650

Tube

28

02896-11012

O-ring, (Kit : K13)

29

707-86-55660

Tube

30

02896-11015

O-ring, (Kit : K13)

31

01010-80850

Bolt

32

01643-30823

Washer

33

07372-21035

Bolt

34

01643-51032

Washer

35

07000-13025

O-ring, (Kit : K13)

36

707-88-50540

Bracket

37

707-88-50550

Bracket

38

707-88-21710

Band

39

07283-32236

Clip, Pipe

40

01597-01009

Nut

41

01643-31032

Washer
