Запчасти Komatsu PC138US-8 РУКОЯТЬ, ДОПОЛН. ГИДРОЛИНИЯ (№-) РУКОЯТЬ, MM С -ДОПОЛН. АКТУАТОР ТРУБЫ, УСИЛ.ENED ТИП, ЕС ARRANGEMENT

1

203-62-64340

Tube

2

07097-20614

Hose

3

07371-30640

Flange, Split

4

07372-21035

Bolt

5

01643-51032

Washer

6

07000-13025

O-ring

7

22B-62-19410

Clamp

8

203-62-43380

Cushion

9

01010-81270

Bolt

10

01643-31232

Washer

11

07371-30640

Flange, Split

12

07372-21035

Bolt

13

01643-51032

Washer

14

07000-13025

O-ring

15

201-973-6810

Nipple

16

07002-13334

O-ring

16

203-973-5803

Valve Assembly

17

07000-13031

O-ring

18

04025-00412

Pin, Spring

19

04064-03015

Ring, Snap, for Shaft Side

20

Body

21

Shaft

22

07000-13025

O-ring

23

203-973-6610

Plate

24

01010-80825

Bolt

25

01643-30823

Washer

26

21T-72-14930

Boss

27

01010-81025

Bolt

28

01643-31032

Washer

29

07002-13334

O-ring

30

22B-973-2150

Elbow

31

22B-973-2120

Plug

32

203-00-56640

Plate, Arrow Mark

33

22B-62-28810

Tube

34

07097-21014

Hose, Flange Type

35

07371-31049

Flange, Split

36

07372-21035

Bolt

37

01643-51032

Washer

38

07000-13032

O-ring

39

22B-62-28820

Clamp

40

22B-62-28760

Cushion

41

01010-81030

Bolt

42

01643-31032

Washer

43

22B-62-28840

Joint

43

22B-62-28850

Valve Assembly

44

07000-13031

O-ring

45

04025-00412

Pin, Spring

46

04064-03015

Ring, Snap, for Shaft Side

47

Body

48

Shaft

49

07000-13025

O-ring

50

203-973-6610

Plate

51

01010-80825

Bolt

52

01643-30823

Washer

53

21T-72-14930

Boss

54

22B-70-21640

Pipe

55

01010-81025

Bolt

56

01643-31032

Washer
