Запчасти Komatsu PC138US-8 ЦИЛИНДР РУКОЯТИ, ВНУТР. ЧАСТИ (/) (№-) ЦИЛИНДР РУКОЯТИ, С ДВОЙН. OFFSET СТРЕЛА, С РУКОЯТЬ HOLDING КЛАПАН

|$0

707-03-00331

Cylinder Assembly

|$1

707-03-00330

Cylinder Assembly

1

707-14-11080

Cylinder

2

707-58-75890

Rod

3

21Y-70-31470

Bushing

4

07145-00080

Seal, Dust, (Kit : K10, K11)

5

22B-70-23620

Bushing

6

07145-00070

Seal, Dust, (Kit : K10, K11)

7

07020-00000

Fitting, Grease

8

707-71-80230

Plunger

9

04260-00635

Ball, Steel

10

707-71-91270

Cap

11

707-27-11650

Head, Cylinder

12

07179-13089

Ring, Snap

13

707-56-75740

Seal, Dust, (Kit : K10, K11)

14

707-51-75030

Packing, Rod, (Kit : K10, K11)

15

707-51-75650

Ring, Buffer, (Kit : K10, K11)

16

07000-15100

O-ring, (Kit : K10, K11)

17

707-35-31010

Ring, Back-up, (Kit : K11)

17

707-35-91130

Ring, Back-up, (Kit : K10)

18

707-52-90501

Bushing

19

707-75-75110

Ring, Snap

20

01010-81670

Bolt

21

01643-51645

Washer

22

721-36-11020

Piston

23

707-44-11150

Ring, Piston, (Kit : K10, K11)

24

707-39-11150

Ring, Wear, (Kit : K10, K11)

25

707-44-11911

Ring

26

01310-01216

Screw

27

07000-15070

O-ring, (Kit : K10, K11)

28

707-35-30700

Ring, Back-up, (Kit : K11)

28

707-35-90360

Ring, Back-up, (Kit : K10)

29

707-83-13010

Valve

30

07750-01628

Spring

31

707-87-14070

Plug

32

07002-12034

O-ring, (Kit : K10, K11)
