Запчасти Komatsu PC138US-8 ЦИЛИНДР СТРЕЛЫ, ЛЕВ. (№-) ЦИЛИНДР СТРЕЛЫ, С ДВОЙН. OFFSET СТРЕЛА, СТУПЕНИ, ДЛЯ MACHINE С СТРЕЛА HOLDING КЛАПАН, С СИГНАЛИЗ. ПЕРЕГРУЗКИ

|$0

707-01-0AN00

Cylinder Assembly,L.H.

1

707-13-10550

Cylinder

2

721-58-70220

Rod

3

07020-00000

Fitting, Grease

4

22B-70-23620

Bushing

5

07145-00070

Seal, Dust, (Kit : K07)

6

22B-70-23620

Bushing

7

07145-00070

Seal, Dust, (Kit : K07)

8

707-71-32470

Collar

9

07000-15095

O-ring, (Kit : K07)

10

707-71-70780

Plunger

11

707-35-91060

Ring, Back-up, (Kit : K07)

12

707-27-10750

Head, Cylinder

13

707-56-70740

Seal, Dust, (Kit : K07)

14

07179-12084

Ring, Snap

15

707-51-70030

Packing, Rod, (Kit : K07)

16

707-51-70650

Ring, Buffer, (Kit : K07)

17

707-52-90471

Bushing

18

707-75-70110

Ring, Snap

19

07000-15095

O-ring, (Kit : K07)

20

707-35-91060

Ring, Back-up, (Kit : K07)

21

01010-81465

Bolt

22

705-17-04980

Washer

23

707-36-10760

Piston

24

707-44-10250

Ring, Piston, (Kit : K07)

25

707-39-10550

Ring, Wear, (Kit : K07)

26

707-44-10911

Ring

27

01310-01216

Screw

28

707-34-60030

O-ring, (Kit : K07)

29

707-35-90730

Ring, Back-up, (Kit : K07)

30

707-86-55160

Tube,L.H.

31

02896-11012

O-ring, (Kit : K07)

32

01010-80850

Bolt

33

01643-30823

Washer

34

01010-81030

Bolt

35

01643-31032

Washer

36

07000-13025

O-ring, (Kit : K07)

37

707-88-50520

Bracket

38

707-88-21720

Band

39

07372-21035

Bolt

40

01643-51032

Washer
