Запчасти Komatsu PC138US-8 КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) (№-) КОНЕЧНАЯ ПЕРЕДАЧА, ДЛЯ TRACTION UP КОНЕЧНАЯ ПЕРЕДАЧА 1 SPEED
№
Артикул
Название
Примечание
Количество
|$0
22B-Z58-1510
Motor Assembly
|$1
22B-60-11351
Motor Assembly
|$2
TZ467B200000-J
Motor
|$3
TZ463B200000-A
Motor
|$4
TZ460B2205-00
Cylinder and Piston Kit
|$5
TZ460B2105-00
Piston Kit
|$6
Piston Assembly
1
Piston
2
Shoe
3
Cylinder Block
4
Retainer Plate
5
Bowl, Thrust
6
Washer
7
Washer
8
Spring
9
Ring
10
Pin, Snap
10
TZ220B2070-01
Piston Assembly
11
Piston
12
Shoe
13
TZ460B2002-02
Shaft
14
TZ460B200303-J
Plate
14
TZ460B200303-A
Plate, Swash
15
TZ460B2009-01
Plate
16
TZ481B2012-00
Piston
17
TZ481B2013-00
Spring
18
TZ460B2015-00
Disc
19
TZ100A2016-00
Plate
20
TZTCN-34-54-11
Seal, Oil, (Kit : K02)
21
TZ481B2035-00
O-ring, (Kit : K02)
22
TZ481B2039-00
O-ring, (Kit : K02)
23
TZNJ207R1SH6C3
Bearing
24
TZNJ204RC3
Bearing
25
TZ460B2076-01
Plate
26
TZ200B2074-00
Plate
26
TZ100A2051-00
Plug
27
TZ263B2077-01
Pin
28
TZ200B2085-00
Spring
28
TZ467B400000-D
Valve, Control
28
TZ467B410000-D
Flange Assembly
28
TZ467B410100-D
Flange Kit
29
Flange
30
Spool
31
Orifice
31
TZ483B411000-A
Spool Kit
32
Spool
33
Stopper,Oil
34
TZ100A2021-00
Plug
35
TZ100A2051-00
Plug
36
TZ140F205200-C
Stopper
37
TZ100A2053-01
Plug
38
TZ100A2054-01
Valve
39
TZ100A2055-00
Spring
40
TZ100A2057-01
Spring
41
07000-13032
O-ring, (Kit : K02)
42
07000-12020
O-ring, (Kit : K02)
43
07000-12018
O-ring, (Kit : K02)
44
TZGDL1-16-S
Plug, Hexagon Head
45
TZGM1-8-S
Plug, Hexagon Head
46
TZ610B2021-00
Plug
47
TZ272B2089-00
Spring
48
0426-00952
Ball
49
01252-30865
Bolt
50
07002-12034
O-ring, (Kit : K02)
51
TZSW-M8
Washer
52
TZS0607
Orifice
53
TZ976B2079-00
Filter
54
07000-12010
O-ring, (Kit : K02)
55
TZ512B2021-00
Plug
56
04260-00793
Ball
57
07000-12011
O-ring, (Kit : K02)
58
TZ850A0006-00
Plate, Name
59
TZJB1354-5-12
Pin
60
01252-31440
Bolt
Выбрано товаров: 74
