Запчасти Komatsu PC138US-8 ПРАВ. КРЫШКА(№-) ПРАВ. COVER, БЕЗ ТОПЛИВН. DISCERNMENT ДАТЧИК

|$0

22B-54-21600

Cover Assembly

1

Cover,R.H.

2

22B-54-22390

Seal

3

07270-21008

Tube

4

22B-54-12990

Seal

5

01010-81245

Bolt

6

01643-31232

Washer

7

22B-54-21612

Cover,R.H.

8

01010-81225

Bolt

9

01643-31232

Washer

10

01010-81245

Bolt

11

01643-31232

Washer

12

22B-01-21230

Cover

13

22B-01-21240

Sheet

14

22B-01-21351

Plate

15

01010-81025

Bolt

16

01643-31032

Washer

17

22B-46-24111

Cover,R.H.

18

22B-46-24361

Lock Assembly

19

120-06-24110

Grommet

20

22B-54-19970

Plate

21

01010-81020

Bolt

22

01643-31032

Washer

23

22B-46-24151

Sheet

24

22B-46-24121

Bracket

25

203-54-62180

Hinge,Welded

26

01010-81225

Bolt

27

130-43-64260

Collar

28

01010-81230

Bolt

29

175-54-34170

Washer

30

22B-46-24141

Bracket

31

01010-81225

Bolt

32

175-54-34170

Washer

33

20Y-54-11611

Stopper

34

01580-11008

Nut

35

22B-46-24180

Spring

36

01023-10512

Screw

37

22B-46-24170

Rod

38

01643-30823

Washer

39

04050-12015

Pin, Cotter
