Запчасти Komatsu PC138US-8 ГИДРОЛИНИЯ РУКОЯТИ И КОВША(/) H ГИДРАВЛИКА

1

22B-62-23492

HOSE, 1900MM

|$5

21U-62-34740

BAND, ORANGE

2

22B-62-23512

HOSE, 1990MM

|$7

21U-62-34730

BAND, GREEN

3

22B-62-23522

HOSE, 1740MM

|$9

21U-62-34760

BAND, RED

4

22B-62-23532

HOSE, 1830MM

|$11

21U-62-34750

BAND, BLUE

5

22B-54-22411

BRACKET

6

01010-81655

BOLT

7

01643-31645

WASHER

8

08034-20834

BAND

9

22B-62-22340

CUSHION

10

22B-62-22330

CUSHION

11

22B-62-22320

CUSHION

12

22B-62-22290

CUSHION

13

01010-81235

BOLT

14

01643-31232

WASHER

15

22B-62-21321

PLATE

16

22B-62-23971

HOSE, 870MM

|$31

21U-62-34720

BAND, BLACK

17

22B-62-23321

HOSE, 820MM

|$33

21U-62-34720

BAND, BLACK

|$34

21U-62-34710

BAND, YELLOW

18

22B-62-23291

HOSE, 850MM

|$36

21U-62-34730

BAND, GREEN

|$37

21U-62-34710

BAND, YELLOW

19

22B-62-23331

HOSE, 950MM

|$39

21U-62-34780

BAND, BROWN

|$40

21U-62-34710

BAND, YELLOW

20

22B-62-23331

HOSE, 950MM

|$42

21U-62-34740

BAND, ORANGE

|$43

21U-62-34710

BAND, YELLOW

21

22B-62-23351

HOSE, 860MM

|$45

21U-62-34770

BAND, WHITE

22

22B-62-23361

HOSE, 1310MM

|$47

21U-62-34780

BAND, BROWN

23

22B-06-21540

WIRING HARNESS

24

7861-93-1840

SENSOR

25

08211-00720

CLIP
