Запчасти Komatsu PC138US-8 КЛАПАН ПЕРЕГРУЗКИ (ДЛЯ ЦИЛИНДРА РУКОЯТИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22B-70-22710

VALVE ASSEMBLY

|1

22B-70-22311

VALVE ASSEMBLY

|1

22B-70-22310

VALVE ASSEMBLY

|1

702-21-18130

VALVE, PILOT

|1

702-21-08831

VALVE, PILOT

|1

702-21-08830

VALVE, PILOT

1

VALVE BODY

2

SPOOL

3

702-21-38510

CASE

4

RETAINER, D=2.0MM

|4

RETAINER, D=1.7MM

|4

RETAINER, D=2.3MM

5

702-21-38430

FLANGE

6

702-21-38440

SPRING

7

702-21-38530

SPRING

8

702-21-38460

O-RING

9

702-21-38470

O-RING

10

702-21-38480

PLUG

11

01252-60620

BOLT

|11

01252-30620

BOLT

12

01252-60825

BOLT

|12

01252-30825

BOLT

13

01252-60835

BOLT

|13

01252-30825

BOLT

14

01641-20608

WASHER

15

07000-12021

O-RING

16

702-21-39690

VALVE

|16

709-74-92810

VALVE

17

709-75-92220

SPRING

18

700-93-11320

O-RING

19

700-93-11330

RING, BACK-UP

20

709-70-79800

VALVE, RELIEF

21

700-80-64220

RING, BACK-UP

22

700-22-11410

O-RING

23

07000-13024

O-RING
