Запчасти Komatsu PC138US-8 ХОД MTOR (КОНЕЧНАЯ ПЕРЕДАЧА ASSEMBLY) (GMVL ТИП) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

22B-60-11351

MOTOR ASSEMBLY

|$2

22B-60-11350

MOTOR ASSEMBLY

|$4

TZ476B1000-00

FINAL DRIVE ASSEMBLY

1

TZ420B1001-00

HUB,MOTOR

|$6

TZ467B1102-00

SPINDLE KIT

|$7

TZ467B1132-00

SPINDLE ASSEMBLY

2

SPINDLE

3

FLANGE,END

4

TZ481B1019-00

BOLT

5

TZ671B1034-01

PIN

6

TZ481B1037-00

WASHER

|$13

TZ481B1104-01

RV GEAR ASSEMBLY

|$14

TZ481B1204-00

RV GEAR KIT

7

GEAR

8

GEAR

9

SHAFT

10

SPACER

11

BEARING

12

BEARING

13

TZ482B1006-00

GEAR

|$22

TZ482B1107-00

SPUR GEAR KIT

14

SPUR GEAR

15

TZ481B1008-01

COVER

16

TZ460B1024-01

COUPLING

17

TZ225B1017-00

PIN

18

TZ200A1020-00

SNAP RING KIT

19

TZ481B1021-01

BEARING

20

04064-03515

RING,BACK-UP

21

07000-11007

O-RING (KIT)

22

TZJW1516-G41-9

O-RING (KIT)

23

TZARP568-453-7

O-RING (KIT)

24

TZ300-328-40-B

FLOATING SEAL KIT

|$34

TZES100-300-B

SEAL (KIT)

25

TZ610B2021-00

PLUG

26

TZJB1176M12-32

BOLT

27

04260-01111

BALL

28

TZJB1354-10-28

PIN

29

07000-12018

O-RING (KIT)

K

TZ467B9000-00

SERVICE KIT
