Запчасти Komatsu PC138US-8 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) (№-) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XM291

CYLINDER GROUP

|1

707-01-0L681

CYLINDER ASSEMBLY, ARM

1

707-13-11210

CYLINDER, ARM

2

707-58-75840

ROD

3

22B-70-23620

BUSHING

4

07145-00070

SEAL, DUST (KIT)

5

22B-70-23620

BUSHING

6

07145-00070

SEAL, DUST (KIT)

7

707-71-32460

HEAD

8

07000-15100

O-RING (KIT)

9

707-71-70810

PLUNGER

10

707-35-31010

RING, BACK-UP (KIT)

11

707-71-80290

PLUNGER

12

04260-00635

BALL

13

707-71-91270

CAP

14

707-27-11650

HEAD, CYLINDER

15

144-63-94170

SEAL, DUST (KIT)

16

07179-13089

RING, SNAP

17

707-51-75030

PACKING, ROD (KIT)

18

707-51-75650

RING, BUFFER (KIT)

19

07000-15100

O-RING (KIT)

20

707-52-90501

BUSHING

21

707-75-75110

RING, SNAP

22

01010-81670

BOLT

23

01643-51645

WASHER

24

707-35-31010

RING, BACK-UP (KIT)

25

721-36-11020

PISTON

26

707-44-11150

RING, PISTON (KIT)

27

707-39-11150

RING, WEAR (KIT)

28

707-44-11911

RING

29

01310-01216

SCREW

30

07000-15070

O-RING (KIT)

31

707-35-30700

RING, BACK-UP (KIT)

32

707-83-13010

VALVE

33

07750-01628

SPRING

34

07002-12034

O-RING (KIT)

35

707-87-14070

PLUG

36

707-86-55540

TUBE

37

02896-11015

O-RING (KIT)

38

707-88-50110

BRACKET

39

707-88-26250

BAND

40

07372-21035

BOLT

41

01643-51032

WASHER

42

07283-32236

CLIP

43

01597-01009

NUT

44

01643-31032

WASHER

45

01010-80850

BOLT

46

01643-30823

WASHER

47

07000-13025

O-RING (KIT)

48

07372-21035

BOLT

49

01643-51032

WASHER

50

707-88-33030

CAP

51

07371-30640

FLANGE, SPLIT

52

02789-00522

PLUG

K

707-99-38820

SERVICE KIT, ARM CYLINDER
