Запчасти Komatsu PC138US-8 ОСНОВН. НАСОС (/9) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-3D-00020

PUMP

|$3

708-3D-01020

PUMP SUB ASSEMBLY

1

708-2L-34120

SLIDER

|$5

708-3D-04610

VALVE ASSEMBLY,PC

2

708-2L-06660

PISTON ASSEMBLY,SERVO

3

708-2L-35680

SEAL

4

708-3D-15310

PLUG

5

708-2L-35760

BALL

6

708-2L-35770

PLUG

7

708-2L-35690

SEAL

8

708-3D-15320

PIN

9

708-2L-35860

SPOOL

10

708-2L-35630

RETAINER

11

708-2L-35641

SEAT

12

708-3D-15410

SPRING

13

708-2L-35730

SPRING

14

708-2L-35650

SEAT

15

708-3D-15420

SPRING

16

708-2L-34330

SCREW

17

07000-B3034

O-RING

18

708-2L-35210

RING,BACK-UP

19

708-2L-35710

SEAL

20

708-2L-35270

PLUG

21

07000-B2011

O-RING

22

07000-B3045

O-RING

23

708-2L-35750

RING

24

708-2L-34230

COVER

25

01580-10806

NUT

26

708-2L-35290

NUT

27

708-2L-35670

RING,WIRE

28

01252-61440

BOLT
