Запчасти Komatsu PC138US-8 МАРКИРОВКА (АНГЛ.) (№9-) U МАРКИРОВКА

1

22B-00-21712

PLATE

2

22B-00-21220

PLATE

3

09803-A0481

PLATE, WARNING, WINDOW LOCK

4

09963-A1640

TAG, DANGER, DO NOT OPERATE

5

206-00-K1010

PLATE, SWING PARKING BEAKE/POMP ON, SWITCH

6

22B-00-21641

PLATE, FUSE BOX

7

22U-00-11910

PLATE, NO PASSENGER

8

22U-00-11920

PLATE, CAUTION

9

22B-00-21670

PLATE, LOCK FOR FRONT LOWER WINDOW

10

22B-00-21170

OIL CHART, LUBRICATING STANDARD CHART

11

09659-A057B

PLATE, WARNING, EXPLOSION HAZARD

12

20J-00-11271

PLATE, WARNING, QUICK COUPLER

13

09133-A2321

PLATE, DANGER, KEEP OFF SWING AREA

14

09134-A1681

PLATE, DANGER, KEEP OFF WORKING AREA

15

09653-A0481

PLATE, WARNING, HIGH TEMPERATURE

16

09653-A0481

PLATE, WARNING, HIGH TEMPERATURE

17

09669-0000E

PLATE, SYMBOL, FUEL FILTER

18

04418-13060

SCREW

19

09601-08000

PLATE, NAME (LIMITED SUPPLY)

20

09659-A057B

PLATE, WARNING, EXPLOSION HAZARD

21

203-00-31120

PLATE, INSTRUCTION, INSTRUCTION HYDRAULIC OIL GAUGE

22

21U-98-31160

PLATE, MARK, LOCATION OF CENTRE OF GRAVITY, CENTRE OF GRAVITY

23

09960-00801

MARK, LIFT POINT

24

09960-00802

MARK, TIE DOWN POINT

25

22B-00-21190

PLATE, HOOK POSITION, ILLUSTRATION OF SLINGING

26

20E-00-K1120

PLATE, INSTRUCTION, AIR CLEANER ELEMENT MAINTENANCE

27

09667-A0481

PLATE, CAUTION, ROTATING OBJECT

28

09805-C0481

PLATE, CAUTION, DO NOT GET ON

29

09805-A0481

PLATE, CAUTION, DO NOT APPROACH

30

09808-A0881

PLATE, WARNING, BATTERY CABLES

31

09664-60011

PLATE, DANGER, BATTERY

32

20U-98-22651

DECAL, DANGER, BATTERY, SAFETY EXPLOSION OR BURNING

33

09664-60011

PLATE, DANGER, BATTERY

34

09657-A0881

PLATE, WARNING, TRACK ADJUSTMENT

35

22B-00-11340

DECAL, WASHER TANK

36

14X-98-35181

PLATE, REFLECTOR

37

20E-00-K1710

PLATE, QUALITY CERTIFIED MARK

38

09696-40100

PLATE, NOISE LEVEL, SOUND POWER LEVEL

39

09696-50072

PLATE, NOISE LEVEL, OPERATOR EAR

40

11Y-98-31130

PLATE, SYMBOL, ECOT3

41

09642-A0480

PLATE, SERVICE INSTRUCTION, ENGINE COOLANT AF-NAC

42

09697-00001

PLATE, BATTERY DISCONNECT SWITCH

43

23B-53-71190

PLATE, CAUTION, RADIATOR CAP

44

600-181-1940

PLATE, CAUTION, AIR CLEANER

45

22B-54-22460

ANTI SKID SHEET

46

22B-54-22470

ANTI SKID SHEET

47

22B-54-22480

ANTI SKID SHEET

48

22B-54-22490

ANTI SKID SHEET

49

22B-54-24740

ANTI SKID SHEET

50

22B-00-21160

MARK, MODEL LOGO

51

09690-P1000

PLATE, KOMATSU LOGO

52

09690-M0063

PLATE, KOMATSU LOGO

53

09690-P0450

PLATE, KOMATSU LOGO

54

09690-P1120

PLATE, KOMATSU LOGO
