Запчасти Komatsu PC138US-8 СОЕДИНЕНИЕ КОВША (УСИЛЕНН.) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|$1

22B-70-00241

LINK ASSEMBLY

1

LINK,L.H.

2

22B-70-23660

BUSHING

3

22B-70-23680

BUSHING

4

22B-70-12170

SEAL,DUST

5

21W-70-41440

SEAL,DUST

|$7

22B-70-00251

LINK ASSEMBLY

6

LINK,R.H.

7

22B-70-23660

BUSHING

8

22B-70-23680

BUSHING

9

22B-70-12170

SEAL,DUST

10

21W-70-41440

SEAL,DUST

11

07020-00000

FITTING,GREASE

12

203-70-54110

LINK,L.H.

13

203-70-54120

LINK,R.H.

14

202-70-64151

PIN

15

07020-00000

FITTING,GREASE

16

21Y-70-14770

SPACER, 1.0MM

|16

21Y-70-14770

SPACER, 1.0MM

|$20

21Y-70-14780

SPACER, 2.0MM

|$21

21Y-70-14780

SPACER, 2.0MM

17

01011-81620

BOLT

18

01580-11613

NUT

19

202-70-64163

PIN

20

07020-00000

FITTING,GREASE

21

21Y-70-14710

SPACER, 1.0MM

|$27

21Y-70-14850

SPACER, 2.0MM

22

01011-81620

BOLT

23

01580-11613

NUT

24

22B-70-12420

PIN

25

01011-81640

BOLT

26

01580-11613

NUT

27

22B-70-12420

PIN

28

01011-81670

BOLT

29

01580-11613

NUT
