Запчасти Komatsu PC138US-8 РУКОЯТЬ И ПАТРУБКИ ЦИЛИНДРА КОВША (.M РУКОЯТЬ) (№9-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|$1

203-944-K160

ARM ASSEMBLY

1

ARM

2

20E-70-11220

BRACKET (WELDED)

3

20G-973-K130

BRACKET (WELDED)

4

20J-70-12180

SEAT (WELDED)

5

22B-70-23630

BUSHING

6

203-70-42182

BUSHING

7

22B-70-23670

BUSHING

8

07020-00900

FITTING,GREASE

9

07020-00000

FITTING,GREASE

10

22B-70-12230

SEAL

11

21W-70-41440

SEAL

12

203-70-42121

PIN

13

21W-70-11310

PLATE

14

01010-81230

BOLT

15

01643-31232

WASHER

16

21Y-70-14790

SPACER, 1.0MM

17

21Y-70-14820

SPACER, 2.0MM

18

07020-00675

FITTING,GREASE

19

202-70-52121

PIN

20

21Y-70-14710

SPACER, 1.0MM

21

21W-70-11310

PLATE

22

01010-81230

BOLT

23

01643-31232

WASHER

24

02756-20513

HOSE

25

02756-20413

HOSE

26

203-943-5620

ELBOW

27

203-943-5130

ELBOW

28

01010-81020

BOLT

29

01643-31032

WASHER

30

02782-10422

ELBOW

31

02783-10422

ELBOW

32

02896-11012

O-RING

33

02783-10522

ELBOW

34

02782-10522

ELBOW

35

02896-11015

O-RING

36

07002-12034

O-RING

37

07002-12434

O-RING

38

02756-20407

HOSE

39

22B-62-24440

HOSE, 730MM

40

07371-30500

FLANGE

41

01010-80830

BOLT

42

01643-30823

WASHER

43

07000-13022

O-RING
