Запчасти Komatsu PC138US-8 СТРЕЛА (СТРЕЛА РАБОЧ. ОСВЕЩЕНИЕ ПАЛЕЦ И ГИДРАВЛ ЛИНИЯ) (№9-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|$1

22B-70-K1132

BOOM ASSEMBLY

|$2

22B-70-K1131

BOOM ASSEMBLY

1

BOOM

2

203-70-61310

PLATE (WELDED)

3

22B-62-K1220

PLATE (WELDED)

4

22B-62-K1230

PLATE (WELDED)

5

22B-62-K1240

PLATE (WELDED)

6

22B-62-K1250

PLATE (WELDED)

7

22B-62-K1260

PLATE (WELDED)

8

22B-70-21950

SEAT (WELDED)

9

22B-70-23610

BUSHING

10

07145-00070

SEAL

|$14

22B-70-12230

SEAL

11

21X-54-32350

CAP

12

07145-00070

SEAL

|$19

22B-70-12230

SEAL

13

20Y-06-K2760

WORK LAMP ASSEMBLY

14

22B-70-21970

BRACKET

15

01010-81225

BOLT

16

01643-31232

WASHER

17

22B-06-28251

WIRING HARNESS

18

04434-51012

CLIP

|$28

04434-51012

CLIP

19

08034-40521

BAND

20

01010-81020

BOLT

21

01643-31032

WASHER

22

08193-21012

CLIP

23

01010-81020

BOLT

24

01643-31032

WASHER

25

22B-70-15220

PIN

26

21W-70-11310

PLATE

27

01010-81230

BOLT

28

01643-31232

WASHER

29

20U-70-31340

SPACER, 1.0MM

30

20U-70-31330

SPACER, 0.5MM

31

203-70-42121

PIN

32

21W-70-11310

PLATE

33

01010-81230

BOLT

34

01643-31232

WASHER

35

21Y-70-14830

SPACER, 1.0MM

36

22B-70-21840

TUBE

37

02896-11018

O-RING

38

22B-70-21830

TUBE

39

02896-11015

O-RING

40

22B-62-21520

HOSE, 780MM

41

22B-62-21510

HOSE, 870MM

42

07000-13025

O-RING

43

07371-30640

FLANGE

44

07372-21035

BOLT

45

01643-51032

WASHER

46

22B-62-K1211

TUBE

|$76

22B-62-K1210

TUBE

47

02896-11012

O-RING

48

22B-62-K1430

TUBE

49

02896-11015

O-RING
