Запчасти Komatsu PC138US-8 БОКОВ. КРЫШКА ЛЕВ. (ДЕКА КРЫШКАAND ПОКРЫТИЕ ПОЛА) M ЧАСТИ КОРПУСА

|$1

22B-54-21105

COVER ASSEMBLY

|$2

22B-54-21104

COVER ASSEMBLY

|$3

22B-54-21103

COVER ASSEMBLY

1

COVER

2

22B-54-11743

PLATE

3

22B-54-12660

SHIM

4

01010-81225

BOLT

5

01643-31232

WASHER

6

22B-54-11882

PLATE

7

205-54-51970

DOVE TAIL

8

01010-80616

BOLT

9

01643-30623

WASHER

10

01010-81225

BOLT

11

01643-31232

WASHER

12

22B-54-21481

BRACKET

13

01010-81225

BOLT

14

01643-31232

WASHER

15

22B-54-21523

COVER

|$19

22B-54-21522

COVER

16

203-54-62180

HINGE (WELDED)

17

20Y-54-71371

LOCK (WELDED)

18

20Y-54-71381

HOOK

19

20Y-54-74181

LOCK ASSEMBLY

20

20Y-54-29232

BAR

21

205-54-53550

DOVE TAIL

22

01010-80616

BOLT

23

01643-30623

WASHER

24

01010-81225

BOLT

25

01643-31232

WASHER

26

22B-54-24870

SHEET

27

01010-81235

BOLT

28

01643-31232

WASHER

29

22B-54-21532

COVER

30

22B-54-21581

SHEET (BONDED)

31

22B-54-22990

SHEET (BONDED)

32

01010-81245

BOLT

33

01643-31232

WASHER

34

22B-54-21541

SEAL

35

22B-54-22890

SHEET (BONDED)

|$40

22B-54-21871

COVER

36

COVER

37

22B-54-21891

SHEET (BONDED)

38

01010-81220

BOLT

39

01643-31232

WASHER

40

22B-54-21430

CUSHION
