Запчасти Komatsu PC138US-8 ТОПЛИВН. БАК. (ТОПЛИВН. REFILL НАСОС) (№8-) D ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

22B-04-21710

TANK

|$2

22U-04-21241

STRAINER ASSEMBLY

|$3

22U-04-21200

FLOAT ASSEMBLY

2

22U-04-21210

GUIDE

3

20Y-04-21580

CAP

4

22U-04-21220

FLOAT

5

SCREW

6

07056-18425

STRAINER

7

20Y-04-11161

CAP

|$10

20Y-04-11160

CAP

8

07040-11007

PLUG

9

07002-11023

O-RING

10

22B-04-21131

PLATE

11

01010-81230

BOLT

12

175-54-34170

WASHER

13

22B-04-21490

CAP

14

07289-00035

CLAMP

15

22B-04-21650

COVER

16

01010-81025

BOLT

17

01643-31032

WASHER

18

22B-04-21660

SHEET

19

22B-04-21671

SEAL

20

7861-92-5810

SENSOR

21

07000-13050

O-RING

22

01010-80610

BOLT

23

01643-30623

WASHER

24

22B-04-21621

PLATE

25

07000-13032

O-RING

26

01010-80616

BOLT

27

01643-30623

WASHER

28

01010-81016

BOLT

29

01643-31032

WASHER

30

01011-81645

BOLT

31

01643-31645

WASHER

32

22B-04-11130

PLATE

33

22B-04-21480

PLATE

34

01010-81225

BOLT

35

01010-81230

BOLT

36

124-54-26540

WASHER

37

22B-04-21470

BRACKET

38

01010-81225

BOLT

39

01643-31232

WASHER

40

22B-04-21690

BRACKET

|$44

22B-04-21642

BRACKET

41

01010-81230

BOLT

42

01643-31232

WASHER
