Запчасти Komatsu PC138US-8 ОСНОВН. КОНСТРУКЦИЯ (БЛОК КОНДИЦИОНЕРА) K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$11

22B-979-2701

AIR CONDITIONER A.

1

ND245450-6630

CASE

2

ND245450-6640

CASE

3

ND245450-6650

CASE

4

ND116576-8040

PLATE

|$16

ND446010-4660

EVAPORATOR ASSEMBLY

5

ND446600-1472

EVAPORATOR

6

ND949142-0020

O-RING

7

ND949142-0030

O-RING

8

ND446250-5990

TUBE

9

ND447500-2660

VALVE

10

ND949046-3100

BOLT

11

ND146687-2091

PACKING

12

ND146687-2080

PACKING

13

ND146687-6350

PACKING

14

ND146657-8850

PACKING

15

ND949046-3610

BOLT

16

ND445021-3941

PLUG

17

ND116420-6830

HEATER

18

ND116340-8820

MOTOR ASSEMBLY

19

ND949008-0330

SCREW

20

ND077800-1040

TRANSISTOR

21

ND077500-5890

THERMISTOR ASSEMBLY

22

ND246790-2060

CLAMP

23

ND077500-0650

THERMISTOR

24

ND017661-3700

CLAMP

25

ND063600-4580

SERVO MOTOR ASSEMBLY

26

ND063800-0300

SERVO MOTOR ASSEMBLY

27

ND116660-0600

DOOR

28

ND116640-8051

DUMPER

29

ND116650-9870

DOOR

30

ND017231-1400

CLAMP

31

ND116682-0670

LEVER

32

ND116662-8420

SHAFT

33

ND017212-1720

LOCK

34

ND949001-1730

SCREW

35

ND146687-6360

PACKING

36

ND146687-6370

PACKING

37

ND146687-6380

PACKING

38

ND145530-1210

HOLDER

39

ND949008-0460

SCREW

40

ND116576-8050

PLATE

41

ND116576-8060

PLATE

42

ND116780-4690

LEVER

43

ND116780-4700

LEVER

44

ND116780-4710

LEVER

45

ND116682-7310

LEVER

46

ND116782-1370

LEVER

47

ND116662-8430

SHAFT

48

ND116662-8440

SHAFT

49

ND246470-5631

HARNESS

50

ND246780-1370

CLAMP

51

ND146687-6400

PACKING

52

ND017780-3110

CABLE
