Запчасти Komatsu PC138US-8 ЦИЛИНДР ОТВАЛА (ВНУТР. ЧАСТИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XL700

CYLINDER GROUP,BLADE LIFT, L.H.

G1

707-01-XL710

CYLINDER GROUP,BLADE LIFT, R.H.

1

707-01-0L700

CYLINDER ASS'Y,BLADE LIFT, L.H.

1

707-01-0L710

CYLINDER ASS'Y,BLADE LIFT, R.H.

1

707-13-11220

CYLINDER,BLADE LIFT, L.H.

1

707-13-11230

CYLINDER,BLADE LIFT, R.H.

2

707-58-75750

ROD,PISTON

3

22B-70-23620

BUSHING

4

07145-00070

SEAL,DUST (KIT)

5

07020-00000

FITTING,GREASE

6

22B-70-23620

BUSHING

7

07145-00070

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-11650

HEAD,CYLINDER

10

144-63-94170

SEAL,DUST (KIT)

11

07179-13089

RING,SNAP

12

707-51-75030

PACKING,ROD (KIT)

13

707-51-75650

RING,BUFFER (KIT)

14

07000-15100

O-RING (KIT)

15

707-52-90500

BUSHING

16

707-75-75110

RING,SNAP

17

01010-81670

BOLT

18

01643-51645

WASHER

19

01643-51645

WASHER

20

707-35-91130

RING,BACK-UP (KIT)

21

707-88-84990

BRACKET

22

01010-81675

BOLT

23

721-36-11020

PISTON

24

707-44-11150

RING,PISTON (KIT)

25

707-39-11150

RING,WEAR (KIT)

26

707-44-11911

RING

27

01310-01216

SCREW

28

07000-15070

O-RING

29

707-35-90360

RING,BACK-UP

30

707-86-55560

TUBE,(L.H.)

30

707-86-55570

TUBE,(R.H.)

31

02896-11012

O-RING (KIT)

32

707-86-55240

TUBE,(L.H.)

32

707-86-55270

TUBE,(R.H.)

33

02896-11012

O-RING (KIT)

34

01010-80850

BOLT

35

01643-30823

WASHER

36

707-88-03270

BRACKET,(L.H.)

36

707-88-03280

BRACKET,(R.H.)

37

07000-13025

O-RING (KIT)

38

07283-32236

CLIP

39

01597-01009

NUT

40

01643-31032

WASHER

K

707-99-38790

SERVICE KIT,BLADE CYLINDER
