Запчасти Komatsu PC138US-8 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (KUK OFFSET СТРЕЛА СПЕЦ-Я.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XZJ40

CYLINDER GROUP,(FINAL COATING)

G1

707-01-XAM90

CYLINDER GROUP,BUCKET

|$3

707-01-0AM90

CYLINDER ASS'Y,BUCKET

1

707-13-90260

CYLINDER,BUCKET

2

22B-70-23640

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00900

FITTING,GREASE

5

707-27-90650

HEAD,CYLINDER

6

707-52-90360

BUSHING

7

707-51-60030

PACKING,ROD (KIT)

8

707-51-60650

RING,BUFFER (KIT)

9

07000-15080

O-RING (KIT)

10

707-35-90980

RING,BACK-UP (KIT)

11

707-56-60740

SEAL,DUST (KIT)

12

07179-12074

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

202-63-75120

ROD

16

22B-70-23650

BUSHING

17

22B-70-12170

SEAL,DUST (KIT)

18

07020-00900

FITTING,GREASE

19

707-36-90170

PISTON

20

707-44-90150

RING,PISTON (KIT)

21

707-39-90050

RING,WEAR (KIT)

22

707-44-90911

RING

23

01310-01016

SCREW,NYLON

24

07000-15055

O-RING (KIT)

25

707-35-90920

RING,BACK-UP (KIT)

26

707-75-60110

RING,SNAP,SNAP

27

707-86-48650

TUBE

28

707-86-55660

TUBE

29

07000-13025

O-RING (KIT)

30

01010-80850

BOLT

31

01643-30823

WASHER

32

707-88-21710

BAND

33

707-88-50540

BRACKET

34

707-88-21710

BAND

35

707-88-50550

BRACKET

36

07372-21035

BOLT

37

01643-51032

WASHER

38

07283-32236

CLIP

39

01597-01009

NUT

40

01643-31032

WASHER

41

02896-11012

O-RING (KIT)

42

02896-11015

O-RING (KIT)

K

707-99-27680

SERVICE KIT,BUCKET CYLINDER
