Запчасти Komatsu PC138US-8 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XM670

CYLINDER GROUP,(FINAL COATING)

G1

707-01-XL691

CYLINDER GROUP

|$3

707-01-0L691

CYLINDER ASS'Y,BUCKET

1

707-13-95130

CYLINDER,BUCKET

2

707-58-65801

ROD

3

22B-70-23640

BUSHING

4

07145-00065

SEAL,DUST (K3)

5

07020-00675

FITTING,GREASE

6

22B-70-23650

BUSHING

7

22B-70-12170

SEAL,DUST (K3)

8

07020-00675

FITTING,GREASE

9

707-27-95650

HEAD,CYLINDER

10

144-63-92170

SEAL,DUST (K3)

11

07179-12079

RING,SNAP

12

707-51-65030

PACKING,ROD (K3)

13

707-51-65650

RING,BUFFER (K3)

14

07000-15085

O-RING (K3)

15

707-52-90420

BUSHING

16

707-75-65110

RING,SNAP

17

707-35-90970

RING,BACK-UP (K3)

18

705-17-04980

WASHER

19

01010-81465

BOLT

20

707-36-95040

PISTON

21

707-44-95150

RING,PISTON (K3)

22

707-39-95030

RING,WEAR (K3)

23

707-34-55020

O-RING (K3)

24

707-44-95911

RING

25

01310-01016

SCREW

26

707-35-90610

RING,BACK-UP (K3)

27

707-86-55550

TUBE

28

02896-11012

O-RING (K3)

29

707-88-50120

BRACKET

30

707-88-21730

BAND

31

07372-21035

BOLT

32

01643-51032

WASHER

33

01010-80850

BOLT

34

01643-30823

WASHER

35

01010-81025

BOLT

36

01643-31032

WASHER

37

07000-13025

O-RING (K3)

K

707-99-27780

SERVICE KIT
