Запчасти Komatsu PC138US-8 OFFSET ЦИЛИНДР (ВНУТР. ЧАСТИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-00-XH850

CYLINDER GROUP

|$2

707-00-0H850

CYLINDER ASS'Y

1

707-11-13840

CYLINDER,OFFSET

2

02896-11012

O-RING (KIT)

3

721-58-70510

ROD,PISTON

4

21Y-70-31460

BUSHING

5

07145-00070

SEAL,DUST (KIT)

6

21Y-70-31460

BUSHING

7

07145-00070

SEAL,DUST (KIT)

8

07020-00900

FITTING,GREASE

9

707-29-13841

HEAD,CYLINDER

10

07179-12084

RING,SNAP

11

707-56-70740

SEAL,DUST (KIT)

12

07000-12130

O-RING (KIT)

13

707-52-10700

BUSHING

14

707-51-70211

PACKING,ROD (KIT)

15

07000-12125

O-RING (KIT)

16

07146-02126

RING,BACK-UP (KIT)

17

707-36-13240

PISTON

18

707-44-13150

RING,PISTON (KIT)

19

07156-01315

RING,WEAR (KIT)

20

707-67-52030

NUT

21

707-86-48660

TUBE

22

02896-11012

O-RING (KIT)

23

707-86-48660

TUBE

24

02896-11012

O-RING (KIT)

25

702-21-08512

PILOT VALVE

26

21W-62-42450

NIPPLE

27

07002-12434

O-RING (KIT)

28

707-88-50560

BRACKET

29

707-88-38500

PLATE

30

01010-80616

BOLT

31

01643-30823

WASHER

32

01010-80820

BOLT

33

01643-30823

WASHER

34

707-88-26190

BAND

35

07372-21035

BOLT

36

01643-51032

WASHER

37

02896-11008

O-RING (KIT)

38

02782-10210

ELBOW

39

07002-11423

O-RING (KIT)

K

707-98-43680

SERVICE KIT,OFFSET CYLINDER
