Запчасти Komatsu PC138US-8 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) (KUK OFFSET СТРЕЛА СПЕЦ-Я.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-03-X0330

CYLINDER GROUP,ARM

|$2

707-03-00330

CYLINDER ASS'Y,ARM

1

707-14-11080

CYLINDER,ARM

2

21Y-70-31470

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-75890

ROD,PISTON

5

22B-70-23620

BUSHING

6

07145-00070

SEAL,DUST (KIT)

7

07020-00000

FITTING,GREASE

8

707-27-11650

HEAD,CYLINDER

9

707-52-90500

BUSHING

10

707-51-75030

PACKING,ROD (KIT)

11

707-51-75650

RING,BUFFER (KIT)

12

07000-15100

O-RING (KIT)

13

707-35-91130

RING,BACK-UP (KIT)

14

707-56-75740

SEAL,DUST (KIT)

15

07179-13089

RING,SNAP

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-11020

PISTON

19

707-44-11150

RING,PISTON (KIT)

20

707-39-11150

RING,WEAR (KIT)

21

707-44-11911

RING

22

707-71-80230

PLUNGER

23

04260-00635

BALL

24

707-71-91270

CAP

25

01310-01216

SCREW

26

07000-15070

O-RING (KIT)

27

707-35-90360

RING,BACK-UP (KIT)

28

707-83-13010

VALVE

29

07750-01628

SPRING

30

707-87-14070

PLUG

31

07002-12034

O-RING (KIT)

32

707-75-75110

RING,SNAP

33

707-86-55670

TUBE

34

21Y-62-31831

TUBE

35

07000-13025

O-RING (KIT)

36

01010-80850

BOLT

37

01643-30823

WASHER

38

707-88-95950

BAND

39

21Y-62-31861

BRACKET

40

07372-21035

BOLT

41

01643-51032

WASHER

42

07283-32236

CLIP

43

01597-01009

NUT

44

01643-31032

WASHER

45

702-21-08830

PILOT VALVE

46

07000-13025

O-RING (KIT)

47

01010-80860

BOLT

48

01643-30823

WASHER

49

01010-80850

BOLT

50

01010-80830

BOLT

51

01643-30823

WASHER

K

707-99-38440

SERVICE KIT,ARM CYLINDER
