Запчасти Komatsu PC138US-8 МАРКИРОВКА (АНГЛ.) (ДЛЯ ЕС)(№-) МАРКИРОВКА

Схема запчастей Komatsu PC138US-8 - МАРКИРОВКА (АНГЛ.) (ДЛЯ ЕС)(№-) МАРКИРОВКА
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
24
24
25
25
25
25
26
26
26
26
27
28
29
30
31
32
32
33
33
34
34
34
35
35
36
37
38
39
40
41
42
43
44
44
45
45
45
46
46
47
48
49
50
51
52

Артикул

Название

Примечание

Количество

1

22B-00-21212

PLATE,WARNING

1

22B-00-21211

PLATE,WARNING

1

PLATE, CAUTION,IF WINDOW IS BROKEN OR BECOMES

1

PLATE, SAFETY,WARNING OF MOVING MACHINE

1

PLATE, SAFETY,LOCK THE SAFETY LOCK LEVER

1

PLATE,OPERATING PATTERN

2

22B-00-21220

PLATE,WARNING

2

PLATE, SAFETY,HAZARDOUS VOLTAGE WARNING

2

PLATE, SAFETY,LOCK THE SAFETY LOCK LEVER

2

PLATE, SAFETY,READ OPERATION MANUAL

3

09803-A0481

PLATE, SAFETY,WHEN OPENING WINDOW, LOCK IT

4

09963-A1640

TAG,DO NOT OPERATE

4

09963-03001

TAG,DO NOT OPERATE

5

206-00-K1010

PLATE,SWITCH

5

22B-00-11420

PLATE, SAFETY,SWITCH

6

22B-00-21440

PLATE,FUSE

6

22B-00-21231

PLATE,FUSE

7

20Y-00-K2380

PLATE,RECOMMENDED LUBRICANT

8

22U-00-11910

PLATE, SAFETY,NO PASSENGER

9

22U-00-11920

PLATE, SAFETY,FALLING OBJECTS

10

22B-00-21280

PLATE,LOCK FOR FRONT LOWER WINDOW

11

22B-00-21170

OIL CHART,LUBRICATING STANDARD CHART

12

09659-A057B

PLATE, SAFETY,ACCUMULATOR WARNING

13

20J-00-11271

PLATE,QUICK COUPLER

13

20J-00-11270

PLATE, SAFETY,QUICK COUPLER

14

207-00-76430

PLATE,WARNING OF SWINGING OR BACKING

14

22B-00-21290

PLATE,WARNING OF SWINGING OR BACKING

15

09133-A2321

PLATE, SAFETY,KEEP OFF SWING AREA

16

09134-A1681

PLATE, CAUTION,KEEP OFF WORKING AREA

17

09653-A0481

PLATE, SAFETY,HYDRAULIC OIL INLET

18

09653-A0481

PLATE, SAFETY,RADIATOR CAP

19

09669-0000E

PLATE, CAUTION,FUEL INLET

20

04418-13060

SCREW

21

09601-00001

PLATE, NAME,MACHINE MODEL

22

09659-A057B

PLATE, SAFETY,ACCUMULATOR WARNING

23

203-00-31120

PLATE, INSTRUCTION,HYDRAULIC OIL GAUGE

24

21U-98-31160

PLATE, MARK,CENTER OF GRAVITY

25

09960-00801

MARK,SLING POSITION

26

09960-00802

MARK,TIE DOWN POINT

27

22B-00-21190

PLATE,ILLUSTRATION OF SLINGING

28

20E-00-K1120

PLATE, INSTRUCTION,AIR CLEANER ELEMENT MAINTE.

28

09637-30163

PLATE, INSTRUCTION,AIR CLEANER ELEMENT MAINTE.

29

09667-A0481

PLATE, SAFETY,REVOLVING OBJECT CAUTION

30

09805-C0481

PLATE, SAFETY,DO NOT STEP ON HOOD

31

09805-A0481

PLATE, SAFETY,DO NOT STEP ON COUNTER WEIGHT

32

09808-A0881

PLATE, SAFETY,ELECTRIC SHOCK

33

09664-60000

PLATE, SAFETY,EXPLOSION OR BURNING

34

20U-98-22651

PLATE, CAUTION,EXPLOSION OR BURNING

34

20U-98-22651

PLATE, CAUTION,EXPLOSION OR BURNING

35

09657-A0881

PLATE, SAFETY,ADJUSTING TRACK TENSION

36

22B-00-11340

PLATE, MARK,WASHER TANK

37

14X-98-35181

PLATE,REFLECTION

38

20E-00-K1690

PLATE, CAUTION,ANTI-FREEZE

39

20E-00-K1710

PLATE, CAUTION,QUALITY CERTIFIED

40

09696-40100

PLATE,SOUND POWER LEVEL

41

09696-50072

PLATE,EU NOISE ,OPERATOR

42

11Y-98-31130

PLATE,ECOT 3

43

09642-13000

PLATE, INSTRUCTION

44

22B-54-22460

SHEET,ANTISKID

45

22B-54-22470

SHEET,ANTISKID

46

22B-54-22480

SHEET,ANTISKID

47

22B-54-22490

SHEET,ANTISKID

48

22B-00-21160

MARK,MODEL LOGO

49

09690-P1000

PLATE, MARK,KOMATSU

50

09690-M0063

PLATE, MARK,KOMATSU

51

09690-P0450

PLATE, MARK,KOMATSU

52

09690-P1120

PLATE, MARK,KOMATSU

Выбрано товаров: 67
