Запчасти Komatsu PC138US-8 БОКОВ. КРЫШКА ПРАВ.(№-) ЧАСТИ КОРПУСА

|$2

22B-54-21600

COVER ASS'Y

1

COVER

2

22B-54-22390

SEAL

3

07270-21008

TUBE

4

22B-54-12990

SEAL (BONDED)

5

01010-81245

BOLT

6

01643-31232

WASHER

7

22B-54-21612

COVER

7

22B-54-21611

COVER

8

01010-81225

BOLT

9

01643-31232

WASHER

10

01010-81245

BOLT

11

01643-31232

WASHER

12

22B-01-21230

COVER

13

22B-01-21240

SHEET

14

22B-01-21351

PLATE

14

22B-01-21350

PLATE

15

01010-81025

BOLT

16

01643-31032

WASHER

17

22B-46-24111

COVER

18

22B-46-24361

LOCK ASS'Y

19

120-06-24110

GROMMET

20

22B-54-19970

PLATE

21

01010-81020

BOLT

22

01643-31032

WASHER

23

22B-46-24151

SHEET (BONDED)

24

22B-46-24121

BRACKET

25

203-54-62180

HINGE (WELDED)

26

01010-81225

BOLT

27

130-43-64260

COLLAR

28

01010-81230

BOLT

29

175-54-34170

WASHER

30

22B-46-24141

BRACKET

31

01010-81225

BOLT

32

175-54-34170

WASHER

33

20Y-54-11611

STOPPER

34

01580-11008

NUT

35

22B-46-24180

SPRING

36

01023-10512

SCREW

37

22B-46-24170

ROD

38

01643-30823

WASHER

39

04050-12015

PIN,COTTER
