Запчасти Komatsu PC138US-8 ОСНОВН. КОНСТРУКЦИЯ (OFFSET УПРАВЛ-Е)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

702-16-01270

PILOT VALVE,(SEE FIG. Y1670-21A1)

2

01010-D1020

BOLT

3

01643-71032

WASHER

4

21Y-54-38151

PLATE

5

21Y-54-38170

SHEET (BONDED)

6

01010-81016

BOLT

7

01643-31032

WASHER

8

01010-D1020

BOLT

9

01643-71032

WASHER

10

21Y-54-21150

COVER

11

09455-13016

HINGE (WELDED)

12

01010-D1020

BOLT

13

01643-71032

WASHER

14

21Y-54-21160

PEDAL

15

09415-02512

CAP

16

01583-11408

NUT

17

01641-21423

WASHER

18

21W-62-43980

ELBOW

19

21W-62-43990

ELBOW

20

20T-910-8660

NIPPLE

21

22B-62-25650

ELBOW

22

07000-12011

O-RING

23

02896-11008

O-RING

24

208-62-72610

HOSE, 450MM

25

22B-62-25320

HOSE, 300MM

|$38

21Y-62-31660

HOSE ASS'Y

|$39

22B-62-25601

HOSE ASS'Y

26

207-62-74760

HOSE, 2100MM

26

21U-62-34760

BAND, RED

26

21U-62-34750

BAND, BLUE

27

22B-62-25641

HOSE, 1750MM

27

21U-62-34750

BAND, BLUE

27

21U-62-34760

BAND, RED

28

206-06-61130

SWITCH

29

22B-06-21590

WIRING HARNESS

30

08193-20010

CLIP

31

08053-01510

CLIP

32

01010-81016

BOLT

33

01643-31032

WASHER
