Запчасти Komatsu PC138US-8 ОСНОВН. КОНСТРУКЦИЯ (1 УПРАВЛ. НАВЕСН. ОБОРУД.)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

702-16-04290

PILOT VALVE,(SEE FIG. Y1670-21A0)

2

22U-43-21470

SEAT

3

01010-81025

BOLT

4

01643-31032

WASHER

5

20Y-62-25360

BRACKET

6

01010-81025

BOLT

7

01643-31032

WASHER

8

22B-43-23730

PEDAL

8

22B-43-23610

PEDAL

9

01010-D1045

BOLT

10

01643-71032

WASHER

11

22B-43-23620

PLATE

12

01010-81020

BOLT

13

01643-31032

WASHER

|$43

22B-43-23630

PLATE

14

PLATE

15

22B-43-23650

SHEET (BONDED)

16

01010-81016

BOLT

17

01643-31032

WASHER

18

207-43-81240

CAP

19

22B-43-23660

PLATE

20

01224-70812

SCREW

21

21W-62-43980

ELBOW

22

07000-12011

O-RING

23

02896-11008

O-RING

24

21W-62-43990

ELBOW

25

20T-910-8660

NIPPLE

26

22B-62-25650

ELBOW

27

206-06-61130

SWITCH

28

22B-06-21590

WIRING HARNESS

29

08053-01510

CLIP

30

01010-81016

BOLT

31

01643-31032

WASHER

|$66

22B-62-25601

HOSE ASS'Y

32

207-62-74760

HOSE, 2100MM

32

21U-62-34750

BAND, BLUE

33

22B-62-25641

HOSE, 1750MM

33

21U-62-34760

BAND, RED

34

22B-62-25320

HOSE, 300MM

35

20Y-62-51910

HOSE, 400MM

36

08193-20010

CLIP

37

01583-51408

NUT

38

04434-51810

CLIP

39

01010-81016

BOLT

40

01643-31032

WASHER

41

07095-20213

CUSHION
