Запчасти Komatsu PC138US-8 КЛАПАН ПЕРЕГРУЗКИ (ДЛЯ ЦИЛИНДРА СТРЕЛЫ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

702-21-08810

PILOT VALVE

1

BODY,VALVE

2

SPOOL

3

702-21-38671

PLATE

4

RETAINER, 2.0MM

4

RETAINER, 1.7MM

4

RETAINER, 2.3MM

5

702-21-38741

PLATE

6

702-21-38440

SPRING

7

702-21-38530

SPRING

8

702-21-38460

O-RING

9

702-21-38470

O-RING

10

702-21-38480

PLUG

11

01252-60625

BOLT

12

01252-60840

BOLT

13

01252-60835

BOLT

14

01641-20608

WASHER

15

07000-12021

O-RING

16

709-74-92810

VALVE

17

709-75-92220

SPRING

18

700-93-11320

O-RING

19

700-93-11330

RING,BACK-UP

20

702-21-55620

PLUG

21

07002-11423

O-RING

|$26

709-70-79800

VALVE ASS'Y,RELIEF

22

SLEEVE

23

700-80-64220

RING

24

700-22-11410

O-RING

25

SEAL

26

POPPET

27

PISTON

28

SPRING

29

SEAL

30

07000-13024

O-RING

31

POPPET

32

O-RING

33

PLUG

34

NUT

35

NUT

36

SPRING

37

O-RING

38

SPACER

39

SEAT
