Запчасти Komatsu PC138US-8 ПОВОРОТН. MTOR (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC138US-8 - ПОВОРОТН. MTOR (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
5
6
6
7
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
36
36
36
37
37
37
38
39
40
41
41
42

Артикул

Название

Примечание

Количество

|$1

706-7C-01010

MOTOR ASS'Y

|$4

706-7C-03010

MOTOR SUB ASS'Y

1

706-7C-71110

CASE,MOTOR

2

706-7C-71210

HOUSING

3

706-73-40010

BEARING

4

706-73-42820

PIN

5

706-7C-51110

VALVE

6

706-7C-51120

SPRING

7

706-7C-51130

PLUG

8

07000-13024

O-RING

9

708-7R-11220

PLUG

10

07002-11223

O-RING

11

702-21-55620

PLUG

12

07002-11423

O-RING

13

706-7C-51140

VALVE

14

722-10-91130

SPRING

15

706-7C-51150

PLUG

16

07002-11823

O-RING

17

07000-12145

O-RING

18

01252-61245

BOLT

19

706-7C-41510

SHAFT,DRIVE

20

706-73-43880

BEARING

21

706-7C-41610

PLATE

22

706-73-43890

BEARING

23

706-7C-05110

SPACER KIT

23

SPACER, 1.5MM

23

SPACER, 1.7MM

23

SPACER, 1.9MM

23

SPACER, 2.1MM

23

SPACER, 2.3MM

24

04064-03515

RING,SNAP

25

708-7T-12230

SEAL,OIL

26

04065-04518

RING,SNAP

27

706-7C-41110

BLOCK,CYLINDER

28

706-7C-41310

PLATE,VALVE

29

720-68-19610

PIN

30

706-7C-41210

SHAFT,CENTER

31

706-7C-41410

RING,CENTER

32

706-7C-41420

SPRING

33

706-7C-41910

RETAINER

34

706-73-42270

SCREW

35

706-7C-41740

PISTON SUB ASS'Y

36

706-7C-91210

PLATE

37

706-7C-91220

DISC

38

706-7C-91110

PISTON,BRAKE

39

706-7C-91120

RING,BRAKE

40

07000-12110

O-RING

41

07000-12130

O-RING

42

706-7C-91310

SPRING

Выбрано товаров: 49
